Hantek HDG2022B User Manual

Appendix
HDG2000 Series Arbitrary Waveform Generator
104
Jitter(rms)
Typical(1MHz,1Vpp, 50Ω) ≤5MHz: 2ppm+500ps; > 5MHz: 500ps
Ramp
Linearity
≤1%(1KHz, 1Vpp)
Symmetry
0%~100%
Pluse
Period
33.33ns~1
Ms
40ns~
1Ms
40ns~
1Ms
50ns~
1Ms
50ns~
1Ms
100ns~
1Ms
200ns~
1Ms
Pulse
≥12ns
≥14ns
≥14ns
≥16ns
≥16ns
≥18ns
≥18ns
Leading Edge Time
≥8ns
≥9ns
≥10ns
≥10ns
≥11ns
≥11ns
≥12ns
Overshoot
<3%(1VPP)
Jitter(rms)
Typical(1MHz, 1Vpp, 50Ω)
≤5MHz 2ppm+500ps
> 5MHz 500ps
Arb. Wavefrom Generator
Waveform Length
64M Point
Vertical Resolution
16 Bit
Sample Rate
250MSa/s
Rise/Fall time
Typical(1Vpp):<6ns
Jitter
Typical(1MHz, 1Vpp, 50Ω)
≤5MHz 2ppm+500ps;
> 5MHz 500ps
Amplitude characteristic
Amplitude Range
≤20MHz:2mVpp - 20Vpp; ≤60MHz:2mVpp -15Vpp; ≤80MHz:2mVpp -10Vpp;
≤90MHz:2mVpp - 5Vpp; ≤100MHz:2mVpp - 2Vpp
Accuracy
Typical(1kHz Sine, 0V deviation, >10mVpp, Auto); ±1% of setting ±2mVpp
Amplitude Flatness
≤10MHz:±0.1dB; ≤60MHz:±0.2dB; ≤100MHz:±0.4dB
Resolution
1mv or 4 digits
Impedance
50Ω
Offset Characteristic
Range
|Voffset| < Vmax – Vpp/2
Accuracy
±(1% of setting + 5mV + 0.5% of amplitude)
Modulation Characteristic
Modulation Type
AM, FM,PM,2ASK,2FSK,2PSK,PWM
AM
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
