Appendix
HDG2000 Series Arbitrary Waveform Generator
105
Source
Internal/External
Modulating
Waveforms
Sine, Square, Ramp, Noise, Arb
Frequency
1Hz~500KHz
Depth
0%~120%
FM
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
Source
Internal/External
Modulating
Waveforms
Sine, Square, Ramp, Noise, Arb
Frequency
1Hz~500KHz
Frequency Deviation
0~360
PM
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
Source
Internal/External
Modulating
Waveforms
Sine, Square, Ramp, Noise, Arb
Frequency
1Hz~500KHz
Frequency Deviation
0%~120%
2ASK
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
Source
Internal/External
Modulating
Waveforms
Square of 50% duty cycle
Code Rate
1Hz~500KHz
2FSK
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
Source
Internal/External
Modulating
Waveforms
Square of 50% duty cycle
Code Rate
1Hz~500KHz
2PSK
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
Source
Internal/External
Modulating
Waveforms
Square of 50% duty cycle
Code Rate
1Hz~500KHz
PWM
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
