Hantek HDG2022B User Manual

Appendix
HDG2000 Series Arbitrary Waveform Generator
106
Source
Internal/External
Modulating
Waveforms
Sine, Square, Ramp, Noise, Arb.
Code Rate
1Hz~500KHz
Width Deviation
0% to 100% of Pulse Width
Burst Characteristic
Burst Count
1~2000000000
Gated Source
External trigger
Trigger Source
Internal, External or Manual
Sweep Characteristics
Type
linear
TypeDirection
Up
Sweep time
280 000s
Hold/Return time
280 000s
Trigger Source
Internal, External, Manual
Mark
Falling Edge of Sync signal(programmable)
Frequency Meter
Frequency
1Hz~20MHz
Input Amplitude
TTL Level
Gate time
1s~16s
General Specifications
Interface
USB host, USB Device, SD card, LAN optional
Display
7’’ 64K Color TFT Display, 800*480
Power Voltage
100-120VACRMS(±10%), 45Hz to 440Hz, CATⅡ; 120-240VACRMS(±10%),
45Hz to 66Hz, CATⅡ
Power Consumption
<60W
Weight
3KG
Model
HDG2102C
HDG2072C
HDG2052C
HDG2032C
Main Features
Waveform Length
64M
Bandwidth
100MHz
70MHz
50MHz
30MHz
Frequency
1uHz– 100MHz
1uHz – 70MHz
1uHz – 50MHz
1uHz – 30MHz
Sample Rate
250MSa/s
Voltage resolution
16Bit
SD Card
2GB
Isolation
Between the Channel and GND
