Hantek HDG2022B User Manual

Appendix
HDG2000 Series Arbitrary Waveform Generator
107
Frequency Characteristics
Waveform
Sine, Square, Ramp, Pulse, Noise, Sinc, Exponential Fall, ECG, Gauss, Haver
Sine, Lorentz, Dual-Tone, DC
Sine
1uHz– 100MHz
1uHz – 70MHz
1uHz – 50MHz
1uHz – 30MHz
Square
1uHz – 40MHz
1uHz – 35MHz
1uHz – 30MHz
1uHz – 25MHz
Pluse
1uHz – 30MHz
1uHz – 25MHz
1uHz – 20MHz
1uHz – 15MHz
Ramp
1uHz – 4MHz
1uHz – 3MHz
1uHz – 2MHz
1uHz – 1MHz
White Noise
80MHz
60MHz
60MHz
60MHz
Harmonic
1uHz – 30MHz
1uHz –25MHz
1uHz – 20MHz
1uHz – 15MHz
Arb. Waveform
1uHz – 30MHz
1uHz – 25MHz
1uHz – 20MHz
1uHz – 15MHz
Resolutin
1uHz
Accuracy
±2ppm, 18℃~28℃
Sine Wave Spectrum Purity
Harmonic Distortion
Typical(0dBm) DC-1MHz: <-60dBc; 1MHz-10MHz: <-55dBc;
10MHz-100MHz: <-50dBc
Total Harmonic
Distortion
<0.1% (10Hz-20kHz, 0dBm)
Spurious signal
(non-hormonic)
Typical(0dBm): ≤10MHz: <-65dBc;
>10MHz <-65dBc+6dB/spectrum phase
Phase Noise
Typical(0dBm,10kHz offset,) 10MHz: ≤-115dBc/Hz
Square
Rise /Fall time
<10ns
<12ns
<12ns
<14ns
Overshoot
Typical Value(100KHz, 1Vpp)<3%
Duty Cycle
≤10MHz: 20.0%~80.0%; 10MHz-40MHz: 40.0%~60.0% ; >40MHz: 50.0%(fixed)
Non-symmetry
1% of period+5ns
Jitter（rms）
Typical(1MHz,1Vpp, 50Ω), ≤5MHz 2ppm+500ps; > 5MHz 500ps
Ramp
Linearity
≤1%(Typical, 1kHz, 1VPP, Symmetry 100%)
Symmetry
0% - 100%
Pulse
Period
40ns – 1000000s
50ns – 1000000s
60ns – 1000000s
70ns – 1000000s
Pulse
≥12ns
≥14ns
≥16ns
≥18ns
Leading/Trailing
Edge Time
≥8ns
≥9ns
≥10ns
≥11ns
Overshoot
Typical(1Vpp)<3%
Jitter（rms）
Typical(1MHz, 1Vpp, 50Ω), ≤5MHz 2ppm+500ps; > 5MHz 500ps
Arb. Waveform
