Appendix
HDG2000 Series Arbitrary Waveform Generator
108
Waveform Length
64M Point
Vertical Resolution
16Bit
Sample Rate
250MSa/s
Rise/Fall time
Typical(1Vpp):<6ns
Jitter
Typical(1MHz, 1Vpp, 50Ω), ≤5MHz 2ppm+500ps; > 5MHz 500ps
Amplitude characteristic
Amplitude Range
≤20MHz: 2mVpp—20Vpp; ≤60MHz: 2mVpp—15Vpp; ≤80MHz: 2mVpp—10Vpp;
≤90MHz: 2mVpp—5Vpp; ≤100MHz: 2mVpp—2Vpp
Accuracy
Typical(1kHz Sine, 0V deviation, >10mVpp, Auto); ±1% of setting ±2mVpp
Amplitude
Flatness(relative to
100kHz, 1Vpp Sine
wave)
≤10MHz:±0.1dB ≤60MHz:±0.2dB ≤100MHz:±0.4dB
Units
Vpp
Resolution
1mv or 4 digits
Isolation
<-80dB
Impedance
50Ω(Typical)
Offset Characteristic
Range
|Voffset| < Vmax – Vpp/2
Accuracy
±(1% of setting + 5mV + 0.5% of amplitude)
Modulation Characteristic
Modulation Type
AM FM PM 2ASK 2FSK 2PSK PWM
AM
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
Source
Internal/External
Modulating
Waveforms
Sine, Square, Ramp, Noise, Arb
Frequency
1Hz~500KHz
Depth
0% -- 120%
FM
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
Source
Internal/External
Modulating
Waveforms
Sine, Square, Ramp, Noise, Arb
Frequency
1Hz~500KHz
Frequency Deviation
0~360
PM
