Hantek HDG2022B User Manual

Appendix
HDG2000 Series Arbitrary Waveform Generator
109
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
PM Source
Internal/External
PM Modulating
Waveforms
Sine, Square, Ramp, Noise, Arb
PM Frequency
1Hz~500KHz
PM Phase Deviation
0°~360°
2ASK
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
Source
Internal/External
Modulating
Waveforms
Square of 50% duty cycle
2ASK Code Rate
1Hz~500KHz
2FSK
Carrier Waveforms
Sine, Square, Ramp, Arb. (except DC)
Source
Internal/External
Modulating
Waveforms
Square of 50% duty cycle
Code Rate
1Hz~500KHz
2PSK
2PSK Carrier
Waveforms
Sine, Square, Ramp, Arb. (except DC)
2PSK Source
Internal/External
2PSK Modulating
Waveforms
Square of 50% duty cycle
2PSK Code Rate
1Hz~500KHz
PWM
PWM Carrier
Waveforms
Sine, Square, Ramp, Arb. (except DC)
PWM Source
Internal/External
PWM Modulating
Waveforms
Sine, Square, Ramp, Noise, Arb.
PWM Frequency
1Hz~500KHz
PWM Width
Deviation
0% to 100% of Pulse Width
Burst Characteristic
Burst Count
2000000000
Gated Source
External trigger
Trigger Source
Internal, External or Manual
