Hantek HDG2022B User Manual

Appendix
HDG2000 Series Arbitrary Waveform Generator
110
Sweep Characteristics
Direction
Up
Type
linear
Sweep time
280000s
Hold/Return time
280000s
Trigger Source
Internal, External, Manual
Mark
Falling Edge of Sync signal(programmable)
Frequency Meter
Frequency
1Hz~20MHz
Input Amplitude
TTL Level
Gate time
1s~16s
General Specifications
Interface
USB host, USB Device, SD Card
Display
7’’ 64K Color TFT Display, 800*480 resolution.
Power Voltage
100-240V, 45Hz to 440Hz
Power Consumption
<60W
Weight
3Kg
