Page #24 background imageLoading...
Page #24 background image
Graphic Text
List printing : You can check and keep an
important data
which is set in each parameter.
24
FUZZY CONTROL
Fuzzy control eliminates overshoot using Fuzzy
Logic. Employing Fuzzy control and Auto-
tuning, the controller effectively control as
below.
When the controller starts control at the
position which has a big gap between SV
and PV.
When reducing warming up time
When the load is fluctuating extreamly
When changing a set point value frequently
Target set
value
Set point value
Subsidary target value
measured
value
Fuzzy Logic start
Time (t)
Control output is set in high and low limit as
operating range.
Output limit is -5 ~ 105 % of output.
OUTPUT LIMIT
20 mA
Output signal
12 mA
4 mA
OL-H
Output limit (%)
OL-L setting range
105 %50 %-5 %
When A/D error or input disconnection occur in
auto mode, PID output is cut and than Pre-set
output is operated. (PO Output)
Emergency output
Hold function
Hold function : None
(Picture 1)
HOLD FUNCTION
Without hold function, Low limit alarm will be
ON when increasing temperature. (Picture 1)
SV
(low limit alarm)
Power ON
Alarm output
ON OFF ON OFF
PV
(Picture 2)
SV
(low limit alarm)
Power ON
Alarm output OFF OFF ON OFF
PV
RECORDER
Run/Stop : You can record or stop when you
need.
Feed : Paper can be transmitted forcedly.
Graphic or Text selectable
