7
SPECIFICATION
4
INPUT
OUTPUT
Input
Sampling time
Input resolution
Input impedance
Lead wire tolerable
resistance
Input tolerable voltage
Noise removal rate
Standard
Standard junction temp.
compensation tolerance
Burn-out
Accuracy
Input range
Thermocouple : K, J, E, T, R, S, B, L, N, U, WRe 5-26, PL-
R.T.D : Pt 100 , KPt 100
Direct voltage: 1 ~ 5 V, -10 ~ 20 mV, 0 ~ 100 mV (Free scale type)
250 mS
Below decimal point of measurement range
T/C and mV input : 1
min., V DC : 1
R.T.D : 10 max. / wire
10 V (T/C, R.T.D, Voltage : mV DC), 20 V (Voltage : V DC)
NMRR(normal mode) : 40 dB min.
CMRR(common mode) : 120 dB min. (50/60 Hz
1 %)
T/C, R.T.D: KS, IEC, DIN
1.5 (15 ~ 35 ), 2.0 (0 ~ 50 )
T/C : OFF, Up/Down selectable
R.T.D : Up scale (Detection current : 50 mA)
0.3 % (Full scale)
Refer to “Input signal and Measurement range”
T/C and R.T.D are changeable within range of input signal and measurement
range.
Voltage: min. voltage and max. voltage are available within range of
measurement. Scaling available.
CONTROL OUTPUT
Relay
contact output
SSR drive
voltage output
Current output
(4 ~ 20 mA DC)
Contact capacity : 240 V AC 3 A, 30 V DC 3 A (resistive load), Contact : 1 C
Output operation : P.I.D control, ON/OFF
Proportional cycle : 1 ~ 1,000 sec.
Output limit : 0.0 ~ 100.0 % range, higher limit(OH) or lower limit(OL)
selectable (valid when AT)
ON/OFF hysteresis : 0 ~ 100 %(Full scale)
Time resolution : 0.1 % or 10 mS
ON voltage : 24 V DC min.(resistive load 600
min., 30 mA limit when short)
OFF voltage : 0.1 V DC max.
Proportional cycle : 1 ~ 1,000 sec.
Output operation : P.I.D control
Output limit : 0.0 ~ 100.0 % range, higher limit(OH) or lower limit(OL)
selectable (valid when AT)
Time resolution : 0.1 % or 10 mS
Current output range : 4 ~ 20 mA DC, Resistive load : 600
max.
Accuracy :
0.5 % of full scale (4 ~ 20 mA range), Resolution : Approx. 3,000
Output ripple : 0.3 %(P-P) of max. scale (150 Hz)
Sampling time : 250 mS
Output operation : P.I.D control
Output limit : -5.0 ~ 105.0 % range, higher limit(OH) or lower limit(OL)
selectable (valid when AT)
