8
FUNCTION
OPERATING ENVIRONMENT
Relay
contact output
Contact capacity : 240 V AC 1 A, 30 V DC 1 A(resistive load)
Contact: 1 a
Output points: 2 Points (AL1,AL2)
ALARM
Input correction (Bias): -100.0 ~ 100.0 % for instrument range
Scaling : According to SH, SL of measurement range
Filter : OFF, 1 ~ 120 sec.
3 settings (SV1, SV2 and SV3) and P.I.D setting each
Auto tuning : According to set value (Standard type, Low PV type)
Proportional Band : 0.1 ~ 999.9 % (Max. range)
Integral Time : OFF, 1 ~ 6000 sec.
Derivative Time : OFF, 1 ~ 6000 sec.
ON/OFF control : By selecting output code (OT) “ 0 ”
P.I.D selection : Zone PID/Auto 1,2,3, selectable
Manual Reset : -5.0 ~ 105.0 % of output (valid when I=OFF)
Direct / Reverse action : Changeable by parameter
Preset output limit : -5.0 ~ 105.0 % of output value
ON/OFF hysteresis (HYS) : 0.0 ~ 100.0% of instrument range (valid when
ON/OFF control)
A.R.W(Anti Reset Wind-up) : AUTO, 50.0 ~ 200.0 %
Fuzzy : selection ON or OFF by parameter
Ramp function
Set point : 2 Points
Multi-alarm : High/Low process alarm, High/Low deviation alarm, Hold function
of alarm, Heater break alarm (H.B.A)
Setting range : Process alarm
0 ~ 100 % of instrument range
Deviation alarm
-100 ~ 100 % of instrument range
Measuring point : 1
Response time : According to chart speed
Record type : Thermal line, 203 dpi(8.0 dots/mm) 384 dots / 1 line
Record speed : 24 mm/h ~ 900 mm/h
Paper : Width 57.5 mm, Length 16 m
Measurement input
Control
Alarm output
Record
Installation environment
Normal operation
condition
Influence of ambient
temperature
Continuous vibration (5~14Hz): Forward width 1.2 mm max.
(4~150Hz): 4.9
(0.5 G) max.
Vibration : 14.7
, 15 sec. max. (each 3 direction)
Shock : 147
(15 G), 11 msec max. (6 direction each 3 times)
Panel cutout: Refer to page 11
Ambient temperature : 0 ~ 50
Ambient humidity : 35 ~ 85 % RH (no condensation)
Influence of magnetic : 400 AT/m max.
Warm-up time: 30 min. min.
T/C, Voltage input :
1 V/ or 0.01 %/ of max. range
R.T.D input :
0.05 / max.
Analog output :
0.05 %/ max. (continuous output)
