Under process
Under process
Safety standard
EMC standard
100 ~ 240 V AC (90 ~ 264 V AC)
50/60 Hz
6.0 W max., 10 VA max.
Between primary terminal and secondary terminal : 500 V DC, 20
min.
Between primary terminal and ground : 500 V DC, 20
min.
Between ground and secondary terminal : 500 V DC, 20
min.
Between primary terminal and secondary terminal : 2,300V AC 50/60 Hz for 1 min.
Between primary terminal and ground : 2,300 V AC 50/60 Hz for 1 min.
Between F
G and secondary terminal : 1,500 V AC 50/60 Hz for 1 min.
Power supply
Frequency
Power consumption
Insulation resistance
Dielectric strength
Standard
Communication address
Communication method
Synchronization
Communication sequence
Communication distance
Communication speed
Start bit
Data bit
Parity bit
Stop bit
Communication protocol
Response time
EIA RS485
Max. 31 (1 ~ 99 setting available)
2 wire half duplex or 4 wire half duplex
Start-stop synchronous mode
None
1.2 Km max.
600, 1200, 2400, 4800, 9600 BPS (Speed is changeable by parameter)
1 BIT
7 or 8 BIT
None, even numbers, odd numbers
1 or 2 BIT
PC LINK WITHOUT SUM(0), PC LINK WITH SUM(1)
Reception treatment time + (Response time
10 mS)
POWER SUPPLY
INTERFACE
SAFETY AND EMC STANDARD
External Dimension
96(W)
96(H) 100(D) mm
MODEL
RT9
Weight
530 g
Material
Plastic case(ABS)
STRUCTURE
STORAGE CONDITION
Storage temperature
Storage humidity
Shock
-25 ~ 70
5 ~ 95 % RH (no condensation)
1 m max. in packing condition
