HA120
www.harbingerproaudio.com
8
Power Amp Specifications
POWER AMP
Max Output Power: 120 Watts (@ 4Ω)
88 Watts (@ 8Ω)
INPUTS
Balancedmono: 4Mic/linechannels
2 Aux Inputs
OUTPUTS
Record Out: RCA Pair
CHANNEL STRIPS (4)
VolumeControls: Rotary
MASTER SECTION
Rotary Fader: Master
BUILT-IN DIGITAL EFFECT
Digital Delay: (2–150ms)
NOISE
Master output (all faders down): –86dBu
Power amp output (all faders down): –55dBu
THD
@120 Watts: <1%
CROSSTALK (1KHZ@ 0DBU)
Channel fader down < –63dB
FREQUENCY RESPONSE (MIC INPUT TO OUTPUT)
20Hzto20kHzlineleveloutput@+4dBuinto600Ω+1/–3dB
20Hzto20kHzpowerampoutput-1wattinto8Ω+1/–3dB
SENSITIVITY @ MIXER OUTPUT +4DBU
Mic/Line: –50dBu/–35dBu
Tape in: –6dBu
CHANNEL EQUALIZATION
2band+/–15dB
Low EQ: 80Hz Shelving
Hi EQ: 12kHz Shelving
MASTER EQUALIZATION
3band+/–15dB
Low EQ: 80Hz Shelving
Mid EQ: 1kHz Peak
Hi EQ: 12kHz Shelving
MICROPHONE PREAMP E.I.N.
(150Ω terminated, max gain) –122dBm
POWER REQUIREMENTS
AC120
~
50/60Hz
DIMENSIONS
H8.85”xW18.9”xD5.9”
WEIGHT
19 lbs.
