Power Amp Specifications
7
POWER AMP
Max Output Power (watts): 8 Ω–45
4 Ω–60
INPUTS
Balanced mono: 4 Mic/line channels
2 Aux Inputs
OUTPUTS
Record Out RCA Pair
CHANNEL STRIPS (4)
Volume Controls: Rotary
MASTER SECTION
Rotary Fader: Master
BUILT-IN DIGITAL EFFECT
Digital Delay (2–150ms)
NOISE
Bandwith-20Hz to 20kHz (line inputs to master output)
Master output (all faders down): –86dBu
Power amp output, all faders down: –55dBu
THD
Power output, 20Hz to 20kHz 20Hz to 20kHz
@60 watts: 4 Ω <1%
CROSSTALK (1KHz@ 0DBU)
20Hz to 20kHz bandwidth, channel in to master output
Channel fader down –63dB
FREQUENCY RESPONSE (MIC INPUT TO OUTPUT)
20Hz to 20kHz line level o/p @+4dBu into 600 Ω +1/–3dB
20Hz to 20kHz power amp o/p 1 watt into 8 Ω +1/–3dB
SENSITIVITY @ MIXER OUTPUT +4DBU
Mic/Line: –50dBu
Tape in: –6dBu
CHANNEL EQUALIzATION
2 band +/–15dB
Low EQ: 80Hz
Hi EQ: 12kHz
MICROPHONE PREAMP E.I.N.
(150 Ω terminated, max gain)
–122dBm
POWER REQUIREMENTS
100–120/220–240 VAC, 50–60Hz
DIMENSIONS (WxHxD)
18.31”x 6.10”x 8.27”
WEIGHT
16.31 lbs.
Minimum 4 Ω load
