LX8 & LX12 OWNER’S MANUAL
16
Parameter Condition LX8 LX12
Frequency Response Mic In to Main Out (Trim at 0 db) 20 Hz – 22 kHz 20 Hz – 22 kHz
THD Mic In to Main Out (20Hz to 20 kHz) 0.009% 0.009%
Preamp Noise (EIN) 20 Hz to 20 kHz, (150 ohm sources) –121dB –121dB
Residual Output Noise All level controls @ minimum –91dB –91dB
Common Mode Rejection Ratio
(CMRR)
Maximum Gain >68dB @ 1 kHz >68dB @ 1 kHz
Crosstalk
Adjacent Channels –88dB –88dB
Same channel (stereo separation) –82dB –82dB
Input Gain Control Range +15dB to +63 dB +15dB to +63 dB
Phantom Power DC +48V +48V
Equalization
Mono Channel, High ±12dB@ 10 kHz ±12dB@ 10 kHz
Mono Channel, Mid NA ±15dB@ 2.5 kHz
Mono Channel, Low ±12dB@ 100Hz ±12dB@ 100Hz
Output Level Maximum +22 dBu +22 dBu
Maximum Input Levels
Mic +6dBu (with –26dB PAD) +6dBu (with –26dB PAD)
Line Input +21dBu at Unity Gain +21dBu at Unity Gain
Aux Input +6dBu at +15dB Level max +6dBu at +15dB Level max
Input Impedance
Mic 2kΩ, balanced 2kΩ, balanced
Line Input 10kΩ, balanced 10kΩ, balanced
Aux Input 10kΩ, balanced 10kΩ, balanced
Output Impedance
Main 120Ω 120Ω
Control Room, Rec Out 120Ω 120Ω
Headphones 100Ω 100Ω
VU Meters Segments Clip (+16), +6, 0, –6, –10, –20dB Clip (+16), +10, 6,0, –3, –6, –10, -20dB
AC Power Requirements 3-pin mini XLR connector ±15VDC @ 500 mA ±15VDC @ 500 mA
Dimensions L x W x H (shown in Inches) 9.08”L x 7.05”W x 2.40”H 11.64”L x 11.58”W x 2.40”H
Weight (net) Without PSU 2.8 lbs 3.2 lbs
LX8 & LX12 SPECIFICATIONS
