Harbinger VARI LIVE V3412 - V3412;V3415 Specifications

V3400 SERIES OWNER’S MANUAL
8
HARBINGER VARI Series
V3412 V3415
Electronics
DSP
Selectable Voicing (Standard, Club, Speech, Floor
Monitor , Custom (APP)), Sub Cut, and Bass and Treble
knobs all control the internal DSP to customize the sound
Selectable Voicing (Standard, Club, Speech, Floor
Monitor, Custom (APP)), Sub Cut, and Bass and Treble
knobs all control the internal DSP to customize the sound
Limiter
Transparent, dynamic DSP limiter for ideal sound quality
and system protection at maximum volume
Transparent, dynamic DSP limiter for ideal sound quality
and system protection at maximum volume
Smart Stereo
A pair of speakers can be connected for unified volume
and tone control from the first master speaker, with
optimal distribution of mono and audio signals between
both speakers
A pair of speakers can be connected for unified volume
and tone control from the first master speaker, with
optimal distribution of mono and audio signals between
both speakers
Input 1
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
Input 2
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
Input 3
Stereo Line: Left/mono and right 1/4-inch TRS
balanced/unbalanced compatible audio line inputs
Aux: 1/8-inch mini TRS unbalanced input (-10dB)
Bluetooth Audio: with On/Pair and Off buttons plus LED
Stereo Line: Left/mono and right 1/4-inch TRS
balanced/unbalanced compatible audio line inputs
Aux: 1/8-inch mini TRS unbalanced input (-10dB)
Bluetooth Audio: with On/Pair and Off buttons plus LED
Link In XLR balanced +4dBv audio input XLR balanced +4dBv audio input
Mix Out
XLR balanced +4dBv audio output XLR balanced +4dBv audio output
Power Output
2000 Watts Peak, 400 Watts (350+50) RMS 2000 Watts Peak, 400 Watts (350+50) RMS
Bass EQ Knob
+/-12dB Shelf, 65Hz +/-12dB Shelf, 65Hz
Treble EQ Knob
+/-12dB Shelf at 6.5kHz
+/-12dB Shelf at 6.5kHz
Volume
Volume control per channel Volume control per channel
Power Input
100–120V, 220–240V, 50–60Hz, 400w Power Draw 100–120V, 220–240V, 50–60Hz, 400w Power Draw
Features
Removable AC Power Cord Removable AC Power Cord
Front LED indicates power (white) and limiter (red),
rear LEDs indicate clipping (red) per input
Front LED indicates power (white) and limiter (red),
rear LEDs indicate clipping (red) per input
Voicing button and 5 voicing indicator LEDs Voicing button and 5 voicing indicator LEDs
Cabinet/ Drivers
Type 12˝ 2-way vented design 15˝ 2-way vented design
Frequency Response
40-20KHz 40-20KHz
Max SPL@1M
128dB 129dB
HF Driver Compression Driver, 8 Ohm Compression Driver, 8 Ohm
LF Driver 12˝ Driver, 4 Ohm 15˝ Driver, 4 Ohm
Cabinet Polypropolene, with rubber surfaced handles and feet Polypropolene, with rubber surfaced handles and feet
Grille 1.2mm steel 1.2mm steel
Suspension Points
V3412 Is Not Designed For Suspension V3415 Is Not Designed For Suspension
Pole Mount 35mm stand pole with M6 screw 35mm stand pole with M6 screw
Product Dimensions 14.2” x 14.2” x 24.1” 16.5” x 15.0” x 27.1”
Dimensions and
Weights
Packaging Size 18.1” x 18.1” x 28.1” 20.1” x 19.5” x 31.1”
Net Weight 35 pounds 41 pounds
Gross Weight 45 pounds 50 pounds
V3412/V3415 SPECIFICATIONS
