Page 10 For technical questions, please call 1-800-444-3353. Item 69039
Securing Ratchet Tie-downs (22)
Note: Use these instructions in the pages that follow.
1. Thread the strap through the Ratchet’s spindle
as far as it will go.
2. Insert the S-hook of the Ratchet into
the hole in the Corner Leg (23).
3. Lift and lower the Ratchet’s handle to wind
and tighten the strap onto the spindle.
CAUTION: Excessive tightening will damage
straps, Covers, and Corner Legs.
Figure L: Threading Strap Through Spindle
Figure M: Inserting Hook into Corner Leg (23)
Figure N: Tightening Ratchet
Releasing Ratchet Tie-downs (22)
1. Depress the spring-loaded bar on the handle.
2. Open ratchet handle completely.
3. Unwind the strap.
Figure O: Releasing Ratchet
