Harbor Freight Tools 69039 - Parts List and Diagram; Parts List

Page 14 For technical questions, please call 1-800-444-3353. Item 69039
Parts List and Diagram
Parts List
Note: Individual part illustrations not to scale.
Part Description Illustration Qty
1-1 Center Stud 4
1-2 Corner Stud
4
2 Rafter 8
3 Rail 9
4 Bottom Rail
6
5-1
3-Way Ridge
Connector
2
5-2
3-Way Side
Connector A
2
5-3
3-Way Side
Connector B
2
6-1
4-Way Ridge
Connector
2
6-2 4-Way Side Connector 4
7
4-Way Center
Rail Clamp
8
8
3-Way End
Rail Clamp
8
9 Foot 4
11 M6×45 Bolt 12
Part Description Illustration Qty
12 M6 Nut 12
13 M6 Washer
12
14-1 Anchor 4
14-2 Cable - 1′ (30cm) 4
14-3 Cable Clamp
4
15 Pin 4
16 Cotter Pin 4
18 Roof Cover 1
19 Door Cover 1
20 Back Cover 1
21 Rope (24′) (7.3M) 2
22 Ratchet Tie-down 8
23 Corner Leg 4
