Harbor Freight Tools CoverPro - Parts List and Diagram; Parts List Details

V2/*.'K$.*'2(,'B$27/28
V2/*.'K$.*
>)*"3 Individual part illustrations not to scale.
V2/* B".%/$4*$)( ?&&+.*/2*$)( f*C
A
3-Way Ridge
Connector
2
A1
3-Way Side
Connector A
2
A2
3-Way Side
Connector B
2
B
4-Way Ridge
Connector
2
B1
4-Way Side
Connector
4
1 Center Stud 4
2 Corner Stud 4
3 Rafter 8
4 Rail 9
5 Bottom Rail 6
6 Corner Leg 4
7 Foot 4
8 Ratchet Tie-Down 8
V2/* B".%/$4*$)( ?&&+.*/2*$)( f*C
9
3-Way End
Rail Clamp
8
10
4-Way Center
Rail Clamp
8
11-1 Anchor 4
11-2 Cable - 1′ (30cm) 4
11-3 Cable Clamp 4
12
M8x50 Hex
Head Bolt
4
13
M8×50 Round
Head Bolt
12
14 M8 Nut 16
15 Roof Cover 1
16 Door Cover 1
17 Back Cover 1
19* Concrete Anchor 12
* Item not shown.
