30
Chart for recording values
Menu Function 1 - Values 2 - Values 3 - Values
Nozzle /Colour
[ Flow constant ] Flow PPU
[ Speed constant ] Speed UPP
Extended menu
Access the extended menu by pressing both arrow keys at the same
time until the menu changes.
The extended menu written in English only.
NOTE: Re-start the system after leaving the Extended menu.
Menu Function [ choices ]
[ Language ] To select language.
[ GB, DK, F, E, D, Cz, SF, NL, I, S ]
[ Unit ] To set unit of measurement. [ Metric, USA ]
[ ON/OFF valve ] To select EC or EVC/ESC/CB control unit.
[ Present, not present ]
[ Pressure system ] To select pressure system.
[ Equalisation, No equalisation ]
[ Control box ] To indicate control box connection to Scanbox.
[ Connected, Not connected ]
[ Tank volume max ] To pre-set tank volume indicated at start-up.
[ Analog adjust ] To calibrate the optional transducer.
[ max., min., offset in mA ]
[ Analog unit text ] To choose the unit of measurement.
[ Bar, PSI, deg C, deg F, % R.H ]
[ Regulation con. ] For the sensitivity of the pressure regulation
valve.
[ Change SW ver. ] To permit change or update of software.
[ Master reset ] For factory use only.
[ Area totals ] To see total area covered and volume sprayed.
[ Scanbox] For factory use.
