Hardi NAVIGATOR 3000 Supplement To Instruction Book

8.1
8 - Technical specifications
Dimensions
General info
All measures, values and weights are depending on mounted options and specific adjustments.
Overall dimensions
Suspended axle:
Non-suspended axle:
Tank capacities
Wheels 12.4x42” 320/90 R46”
A - Total length 23’ 2” 23’ 2”
B - Total width 11’ 5” 11’ 5”
C - Total height12’ 0” 12’ 3”
D - Draw to axle 14’ 9” 14’ 9”
Wheels 12.4x42” 320/90 R46”
A - Total length 23’ 2”
23’ 2”
B - Total width 11’ 5” 11’ 5”
C - Total height11’ 9” 12’ 0”
D - Draw to axle 14’ 9” 14’ 9”
Main tank capacity 800, 1000 or 1200 gallons
(3000, 3500 or 4000 Liters)
Clean water tank capacity5 gallons (20 Liters)
Flus
h tank capacity 130 gallons (500 Liters)
Foam m arker tank capacity 25 gallons (100 Liters)
