HARDI NAVIGATOR
Specifications
1 Nm = 0.738 lbf-ft
1 bar = 100 kPa = 14.5 psi
TORQUE SETTINGS
Wheel studs
20 mm 337 Nm
Drawbar bolts
Hitch M16 190 Nm Chassis 750
363 / 463 pump
Valve cover bolts 90 Nm Diaphragm bolt 90
General bolts
M12 bolts 77 Nm M16 190
M18 bolts 269 Nm M20 370
TEMPERATURE
Operating temperature range: 2° - 40° C (36° - 104° F)
PRESSURE
Operating pressure for safety valve: 12 bar
MAX Pressure on the pressure manifold: 20 bar
MAX Pressure on the suction manifold: 7 bar
FLOW
EVC
Bypass flow under the EVC pressure adjusting motor
(Pressure motor adjusted for full pressure): 0-1 l/m
Self Cleaning Filter
Bypass flow for each restrictor (Pressure @ 3 bar):
Green - 37 l/m Black - 26 l/m
White - 18 l/m Red - 13 l/m
Agitators
Combined flow from both agitators @ 3 bar:
2.5 mm - 16 l/m 3.0 mm - 25 l/m
DIMENSIONS
Always measure actual sprayer.
Dimensions are dependant on boom, suspension, wheels,
tank and drawbar variations.
Boom Height (mm): 500 - 1750
Track Width (mm): 1500 - 3000
PUMP CAPACITY (at various rpms)
363/
10.0
200 300 400 500 540 600
PRESSURE (bar) CAPACITY (l/min)
0 69 102 135 171
183 200
3 68 100 133 166
180 196
6 66 98 131 164
177 193
9 65 96 129 162 176 190
12 64 95 128 160
173 189
15 (MAX) 63 93 126 157
177 186
463/10.0
200 300 400 500 540 600
PRESSURE (bar) CAPACITY (l/min)
0 101 147 196 245
263 290
3 96 142 191 237
245 282
6 93 138 186 233 250 276
9 90 136 182 226
245 270
12 88 132 179 221 239 266
15 (MAX) 85 130 175 215
235 261
MATERIALS AND RECYCLING
Tank HDPE Hoses PVC / Rubber
Valves Mainly glass-filled PA Fittings PA
When the equipment has completed its working life, it must be
thoroughly cleaned. Tank, hose and synthetic fittings can be
incinerated at an authorised disposal plant. Metallic parts can
be scrapped. Always follow local legislation regarding disposal.
FILTERS
MESH COLOR GAUZE SIZE (mm)
30 Green 0.58
50 Blue 0.30
80 Red 0.18
100 Yellow 0.15
eryT
eziS
roylP
daoL
gnitaR
)aPk(SERUSSERPNOITALFNIDLOCSUOIRAVTA)gK(STIMILDAOLERYT
h/mk03otpusdeepstadesudnaselgnissadettifserytlaidar/saib1-RretspirGcipmylOotylppadeificepsseulaV
.stimildednemmocerrofreilppusruoytcatnocesaelpserytfosdnarbrehtoroF
aPk58aPk001aPk021aPk041aPk061aPk081aPk002aPk022aPk042
42-9.418/6
*041105210931)6(02510461)6(0671---
82-9.4101/6
*012103310841)6(02610571)8(088100020102)01(0112
82-9.6121/8/6
*0741*0561)6(00810791)8(03120822)01(52420652)21(0072
03-4.8101/8/6
*0281*)6(50020322)8(04420462)01(52820003)21(0813-
83-4.8141/01/8
*0502*)6(05225052)8(04725692)01(0813---
83-8.0241/01/8
*0842*5272)8(04030233)01(09530483)21(0804)41(0224-
24-8.0201
*0162*578200230053)01(0873----
.)snoitacilppalluprabwardthgiartsnidesuserytretspirGrofelbissimrepylnoera*dekramsdaol:noitpecxE(,detacidnisaeraserusserpnoitalfnidlocmuminiM
.mumixameraerusserpnoitalfnidnasdaolhcihwrofgnitarylpsetoned)x(
.erusserpnoitalfniniegnahconhtiwylppasdeepssuoiravtastimildaolgniwollofeht,euqrothgihdeniatsuseriuqertonodhcihwsnoitareporoF
deepSmumixaM
h/mk51h/mk52h/mk03h/mk04
sdaoLniesaercnI%
%02+%01+elbatsaemaS%01-
