SPECIFICATIONS 2.1
TORQUE VALUES
The following torque values are included for fasteners that
may be loosened and tightened during Predelivery and
Setup. Any fasteners that are not loosened/removed do not
need to be checked during predelivery and setup.
2005 TOURING MODELS
SPECIFICATIONS
Idle Speed: 950 RPM at
Operating Temperature
Use 950 RPM during Predelivery and Setup adjustments.
Engine idle speed may increase during engine break-in. Use
idle speed listed in the Touring Models Service Manual at Ini-
tial Maintenance check.
NOTE
The idle speed on electronic fuel injected models can only be
set using a diagnostic tool such as DIGITAL TECHNICIAN
(Part No. HD-44750).
Table 2-1. Torque Values
ITEM TORQUE NOTES
Handlebar clamp screws (front and rear) 12-16 ft-lbs 16.3-21.7 Nm Must be checked at set-up.
Clutch inspection cover screws 84-108 in-lbs 9.5-12.2 Nm
FLHT windshield screws 25-30 in-lbs 2.8-3.4 Nm
FLTR windshield screws 6-13 in-lbs 0.7-1.5 Nm
Saddlebag mounting bracket bolts 60-96 in-lbs 6.8-10.8 Nm
Tour-Pak
®
mounting bolts 96-120 in-lbs 10.8-13.5 Nm
FLHR/
FLHP
Nacelle acorn nuts 72-108 in-lbs 8.1-12.2 Nm
Handlebar clamp shroud screws 10-20 in-lbs 1.1-2.3 Nm
Handlebar clamp shroud nut 10-20 in-lbs 1.1-2.3 Nm
Nacelle trim nut 15-20 in-lbs 1.7-2.3 Nm
Table 2-2. Capacities
Component ENGLISH METRIC
Oil tank w/filter (Dry) 4 qt. 3.79 liter
Transmission (Wet) 20-24 oz 591-710 ml
Primary Chaincase 32 oz 946 ml
All touring models except FLHTCSE
2
are shipped with
20W50 Harley-Davidson 360 Motor oil. The FLHTCSE
2
model ships with Syn-3
®
lubricant in the engine, primary
and transmission.
