3-10 2005 PDI: Dyna Models
BRAKE SYSTEM 3.7
BRAKES
1CAUTION
Direct contact with D.O.T. 5 brake fluid can cause eye irri-
tation, swelling, and redness. Avid eye contact. In case of
eye contact flush with large amounts of water and get
medical attention. Swallowing large amounts of D.O.T. 5
brake fluid can cause digestive discomfort. If swallowed,
obtain medical attention. Use in well ventilated area.
KEEP OUT OF REACH OF CHILDREN. (00144a)
See Figure 3-8. View reservoir sightglass and verify fluid
presence. Sightglass should appear dark if fluid is present. If
sightglass is not dark, add brake fluid. See Service Manual.
Use only D.O.T. 5 SILICONE HYDRAULIC BRAKE FLUID.
Figure 3-8. Rear Master Cylinder Shown
4934
