2005 PDI: Softail Models 4-1
SPECIFICATIONS 4.1
TORQUE VALUES
The following torque values are included for fasteners that
may be loosened and tightened during Predelivery and
Setup. Any fasteners that are not loosened/removed do not
need to be checked during predelivery and setup.
2005 SOFTAIL MODELS
SPECIFICATIONS
Idle Speed: 950 RPM at
Operating Temperature
Use 950 RPM during Predelivery and Setup adjustments.
Engine idle speed may increase during engine break-in. Use
idle speed listed in the Softail Models Service Manual at Ini-
tial Maintenance check.
NOTE
The idle speed on electronic fuel injected models can only be
set using a diagnostic tool such as DIGITAL TECHNICIAN
(Part No. HD-44750).
Table 4-1. Torque Values
ITEM TORQUE NOTES
Handlebar clamp screws (front and rear) 12-15 ft-lbs 16.3-20.3 Nm
Brake master cylinder cover screws
(front and rear)
6-8 in-lbs 0.7-0.9 Nm
Battery terminal screws 60-96 in-lbs 6.8-10.9 Nm
Mirror fasteners 60-96 in-lbs 6.8-10-9 Nm
Clutch inspection cover screws 84-108 in-lbs 9.5-12.2 Nm
Table 4-2. Capacities
Component ENGLISH METRIC
Oil tank w/filter (Dry) 3.5 qt. 3.31 liter
Transmission (Wet) 20-24 oz 591-710 ml
Primary Chaincase 26 oz 769 ml
All Softail models except FLSTFSE are shipped with
20W50 Harley-Davidson 360 Motor oil. The FLSTFSE
model ships with Syn-3
®
lubricant in the engine, primary
and transmission.
