2008 MODEL YEAR TECHNICAL FORUM TOURING
ABS Brake System cont.
• 2008 wheel hubs are machined
to accommodate ABS
• Tone ring integral to wheel bearing
• Wheel spacer is the sensor and
is directional
• Non ABS models have different bearings
and additional spacers
• ABS bearings are directional
and are assembled gray side
out / orange side in
Important Service Note:
The use of a magnetic parts tray will
adversely affect ABS wheel bearings
2008 MODEL YEAR TECHNICAL FORUM TOURING
Redesigned Fuse Block
• All fuses under left side cover
• Maxi fuse inserts into block
and will not be installed at the
factory
Data Link Relocation
• Now under left side cover
