SERVICE AND TOOLS2008 MODEL YEAR TECHNICAL FORUM
NEW Balancer Sprocket Shaft
Alignment Tool
HD-48615-gold in color
• Essential Tool
• .019” is the specification
tolerance of the sprockets
• Similar to HD-44064-A
• Verifies balancer sprocket
alignment for Softails
®
• For 2007 and later Softails
®
SERVICE AND TOOLS2008 MODEL YEAR TECHNICAL FORUM
NEW Breakout Box – FL Only
HD-48637
• Essential Tool
• For new FL ECM
• Connector on harness side utilizes
a cam lock system that brings the
mated connectors together fully
Important Service Note:
New connector can be installed
backward; if the large brass pin
is not properly aligned, the
connector could be damaged
and require a new wiring harness.
Warning to align pin printed on the
connecter-see where circled.
