Harley-Davidson Dyna 2008 - Page 104

18
17
16
15
14
8
9
13
12
11
10
7
6
5
4
3
1
2
22
19
20
21
sm03169
12.1. Site glassLubricant
2. 13.Wiper Screw (2)
14.3. Master cylinder reservoirPiston cap
4. 15.O-ring Pivot pin
16.5. BushingPiston
6. 17.Primary cup Brake hand lever
18.7. Retaining ringSpring
8. 19.Handlebar clamp Flat side
20.9. ShoulderT27 TORX screw and washer (2)
10. 21.Gasket Pin
22.11. O-ring grooveCover
Figure 2-63. Front Brake Master Cylinder
3. See Figure 2-64. Place the cardboard insert between the
brake lever and lever bracket.
4. See Figure 2-63. Remove the two T27 TORX screws with
flat washers (9) to detach the handlebar clamp (8) from
the master cylinder reservoir (14).
5. Remove retaining ring (18) from pivot pin groove at bottom
of master cylinder bracket.
6. Remove pivot pin (15) and brake hand lever (17).
7. Carefully remove wiper (2) with pick or similar tool.
8. Remove piston cap (3).
2008 Dyna Service: Chassis 2-33
