4.4AIR CLEANER ASSEMBLY
REMOVAL
1. See Figure 4-1. Remove screw (1) and air cleaner cover
(2).
2. Gently pull both rubber breather tubes (7) from the ele-
ment.
3. Slide clip-nut (5) to the left to allow access to third screw.
Remove three screws (4), bracket (6) and filter element
(8).
4. Gently pull the breather tubes from the breather bolts on
the backplate.
Do not use gasoline or solvents to clean filter element.
Flammable cleaning agents can cause an intake system
fire, which could result in death or serious injury. (00101a)
5. Inspect filter element. See 1.7 AIR CLEANER AND
EXHAUST SYSTEM. Replace the filter element if damaged
or if filter media cannot be adequately cleaned.
6. Inspect seal ring (3) for cracks or tears.Verify that it seals
tightly to backplate. Replace as required.
7. Alternately back out both breather bolts (9) (metric) a few
turns a time while pulling backplate (10) away from
induction module.
8. Continue previous step until breather bolts are clear.
Remove backplate (10), gasket (11) and gasket (12).
Discard gaskets.
9. Wipe inside of air cleaner cover (2) and backplate (10)
with damp cloth to remove dust.
4-4 2008 Dyna Service: Fuel System
