Harley-Davidson Dyna 2008 - Page 330

sm02424
Figure 6-35. Pressing Bearing From Clutch Shell
5
2
7
6
1
3
4
sm02426
1. Steel plate
2. Clutch hub
3. Damper spring seat
4. Damper spring
5. Starter ring gear
6. Primary chain sprocket
7. Narrow friction plate
Figure 6-36. Clutch Stackup
5
4
3
2
1
sm02427
1. Diaphragm spring
2. Jam nut
3. Adjuster screw
4. Retaining ring
5. Bolt (6) (metric)
Figure 6-37. Assembled Clutch
2008 Dyna Service: Drive 6-17
