Harman Kardon AVR 255 Service Manual

FRONT PCB ASSY
Ref. # Part Number
Description
Value
C850 CCBS1H471KBT CAP , CERAMIC(470PF/50V) 470PF 50V
C851 CCBS1H471KBT CAP , CERAMIC(470PF/50V) 470PF 50V
C852 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C855 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C856 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C857 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C862 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C863 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C866 CCEA1HH100T CAP , ELECT 10UF 50V
C867 CCEA1HH100T CAP , ELECT 10UF 50V
C868 CCEA1EH470T CAP , ELECT 47UF 25V
C869 CCEA1EH470T CAP , ELECT 47UF 25V
C870 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V K
C871 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V K
C872 CCEA1CH331T CAP , ELECT 330UF 16V
C873 CCEA1CH331T CAP , ELECT 330UF 16V
C874 CCBS1H101KBT CAP , CERAMIC(100PF/50V) 100PF 50V K
C882 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C888 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C889 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C891 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C892 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C893 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) 0.022UF 50V Z
C894 CCEA1CKS100T CAP , ELECT 10UF 16V
C896 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C897 CCEA1AH471T CAP , ELECT 470UF 10V
C903 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE
C905 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE
D455 CVD1SS133MT DIODE 1SS133
D774 CVD1SS133MT DIODE 1SS133
D775 CVD1SS133MT DIODE 1SS133
D784 CVD1SS133MT DIODE 1SS133
D785 CVD1SS133MT DIODE 1SS133
L702 HLQ02C100KT COIL , AXAIL 10uH
Q451 HVTKRC107MT T.R KRC107M
Q452 HVTKRA107MT T.R KRA107M
Q454 HVTKRC107MT T.R KRC107M
Q701 HVTKRC107MT T.R KRC107M
Q722 HVTKRA107MT T.R KRA107M
Q724 HVTKRC107MT T.R KRC107M
Q725 HVTKRC107MT T.R KRC107M
Q734 HVTKTC2874BT T.R , MUTE KTC2874B
Q735 HVTKTC2874BT T.R , MUTE KTC2874B
Q736 HVTKTC2874BT T.R , MUTE KTC2874B
Q737 HVTKTC2874BT T.R , MUTE KTC2874B
Q738 HVTKRC107MT T.R KRC107M
Q739 HVTKTA1271YT T.R KTA1271Y
Q740 HVTKTC3200GRT T.R KTC3200GR
R452 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R453 CRD20TJ362T RES , CARBON 3.6K OHM 1/5W J
R454 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R701 CRD20TJ103T RES , CARBON 10K OHM 1/5W J
R704 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
R705 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R706 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R708 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R709 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R710 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R711 CRD20TJ470T RES , CARBON 47 OHM 1/5W J
R718 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J
R721 CRD20TJ101T RES , CARBON 100 OHM 1/5W J
R722 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R723 CRD20TJ393T RES , CARBON 39K OHM 1/5W J
R724 CRD20TJ100T RES , CARBON 10 OHM 1/5W J
harman/kardon
AVR 255/230 Service Manual
Page 11 of 144

Harman Kardon AVR 255 Specifications

General

Impedance	8 Ω
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
HDMI	Yes
Audio system	Dolby Digital
Dimensions (WxDxH)	440 x 351 x 151 mm
Power requirements	2 x 65 W
HDMI ports quantity	3
Output power description	192 kHz
S-Video inputs quantity	1
Component video (YPbPr/YCbCr) in	4
Headphone connectivity	-
Product color	Black, Silver

Weight and Dimensions

Weight	13600 g
