Harman Kardon AVR 255 Service Manual

AVR255/230 Electrical Parts List
Ref. # Part Number
Description
Value
CGB1A193Z BADGE , AVR255 BADGE
CGL1A222 INDICATOR , VOLUME INDICATOR
CGU1A318Y ORNAMENT , VOLUME AVR255 ORNAMENT
CGU1A410A25W WINDOW , FIP WINDOW
CGX1A338MBC63 CAP , VOLUME VOLUME CAP
CGX1A390C66X SHEET , AL FRONT AVR255 SHEET
CKC6B145S60 CABINET , TOP AVR350 CABINET
CMH1A214 HOLDER , VOLUME HOLDER
CMZ1A127 FILTER , FIP AVR255 FILTER
CMZ2A090 SHEET , VOLUME SHEET
CTB3+8JFZR SCREW SCREW
CTB4+6FFZR SCREW SCREW
C4B120122 TUBE , UL TUBE
CHE154 CLAMPER , ARM CLAMPER
CJXAVR340MICRO MICRO PHONE ASS'Y ASS'Y
CPG1A855V BOX , OUT CARTON AVR255/230 BOX
CARTAVR255/230 REMOCON TRANSMITTER ASS'Y REMOTE
CGRAVR350/230ZA COVER ASS'Y COVER
CGR2A436 COVER , A AVR350 COVER
CGR2A437 COVER , B AVR350 COVER
CGX1A391C66 ORNAMENT , AL A AVR350 ORNAMENT
CGX1A392C66 ORNAMENT , AL B AVR350 ORNAMENT
CQX1A1318Z MANUAL , INSRTUCTION MANUAL
CQX1A1320Z MANUAL , SETUP AVR155/230 MANUAL
CSA1A018Z FM 1 POLE ANT FM ANT
CSA1A020Z ANT , AM LOOP AM ANT
HQE1A273Z HARMAN IMAGE BROCHURES BROCHURES
CRE1A037 LOCKER LOCKER
FRONT PANEL ASSY
Ref. # Part Number
Description
Value
CGWAVR255/230 FRONT PANEL ASS'Y ASS'Y
CBT1A1064 KNOB , STANDBY AVR355 KNOB
CBT1A1065 KNOB , BACK AVR355 KNOB
CGB1A158Y BADGE , FRONT HARMAN/KARDON BADGE
CGL1A265Y INDICATOR , POWER AVR155 INDICATOR
CGW1A447RHWB24 PANEL , FRONT AVR255/230 PANEL
CHG1A309 RUBBER RUBBER
CHR301 CLAMPER CLAMPER
CLZ9Z028Z FERRITE CORE(21.2X6.4X12.7) FERRITE CORE
CMC1A323 PLATE , SHIELD AVR350 PLATE
CMC2A326 PLATE , EARTH AVR350 PLATE
CMC2A338 PLATE , EARTH AVR350 PLATE
CMD1A555 BRACKET , SIDE (L) BRACKET
CMD2A443 BRACKET , SIDE BRACKET
CMH2A215 HOLDER , LED AVR350 HOLDER
CPE1A009 SHEET , BLIND SHEET
CTB3+10JR SCREW SCREW
CTWS3+10GR SCREW SCREW
CB72 CWC4F2A17A280B CABLE , CARD(17P, 280mm) CARD CABLE
BOTTOM CHASSIS ASS'Y
Ref. # Part Number
Description
Value
CUAAVR255/230 BOTTOM CHAASIS ASS'Y ASS'Y
CHD1A012ZR SCREW , SPECIAL SCREW
CHD1A023R SCREW , SPECIAL SCREW
CHD4A012R SCREW , SPECIAL SCREW
CHE170 HOLDER , PCB HOLDER
CHE36-3 CLAMPER , WIRE CLAMPER
CHG1A104Z CUSHION , RUBBER CUSHION
CHG1A160Z CUSHION , RUBBER CUSHION
CHG1A373 CUSHION , FOOT AVR350 CUSHION
CJA2B044ZA CORD , POWER POWER CORD
harman/kardon
AVR 255/230 Service Manual
Page 9 of 144

Harman Kardon AVR 255 Specifications

General

Impedance	8 Ω
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
HDMI	Yes
Audio system	Dolby Digital
Dimensions (WxDxH)	440 x 351 x 151 mm
Power requirements	2 x 65 W
HDMI ports quantity	3
Output power description	192 kHz
S-Video inputs quantity	1
Component video (YPbPr/YCbCr) in	4
Headphone connectivity	-
Product color	Black, Silver

Weight and Dimensions

Weight	13600 g
