Harman Kardon AVR 260

Leve
l
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
0,2 CGB1A218Z BADGE , AVR260 1
0,2 CGL1A222 INDICATOR , VOLUME AVR130/230/330 1
0,2 CGR3A436 COVER , JACK A 1
0,2 CGR3A437 COVER , JACK B 1
0,2 CGU1A318Y ORNAMENT , VOLUME AVR255 1
0,2 CGU1A410A25W WINDOW , FIP 1
0,2 CGX1A338MBC63 CAP , VOLUME 1
0,2 CGX1A391C66 ORNAMENT , AL A AVR350 1
0,2 CGX1A392C66 ORNAMENT , AL B AVR350 1
0,2 CGX2A390C66X SHEET , AL FRONT AVR255/230 1
0,2 CKC6B145S60 CABINET , TOP AVR350 1
0,2 CMH1A214 HOLDER , VOLUME AVR130/230/330 1
0,2 CMZ1A127 FILTER , FIP AVR255 1
0,2 CMZ2A090 SHEET , VOLUME 1
0,2 CQB1A549Y LABEL , ATTENTION DVD48 1
0,2 CQB1A622 LABEL , SERIAL NO 1
0,2 CTB3+8JFZR SCREW 15
0,2 CTB4+6FFZR SCREW 6
0,2 C4B120122 TUBE , UL 0,1
1 CARTAVR260E-HK REMOCON ASS'Y (57KEY) AVR260 1
1 CHE154 CLAMPER , ARM 0,1
1 CJXAVR340MICRO MICRO PHONE ASS'Y 1
1 CPG1A891V BOX , OUT CARTON 1
1 CPS5A564Z PAD , SNOW L AVR155 1
1 CPS5A565Z PAD , SNOW R AVR155 1
1 CQB1A907Z LABEL , BAR CODE AVR154 1
1 CQB1A928Z LABEL , MADE IN PRC 2
1 CQS1A001 RIBON , BAR CODE SONY(TR-4070) 0,1
1 CQXAVR260/240 INSTRUCTION MANUAL ASS'Y 1
0,2 CQB1A971 LABEL , BAR CODE(MANUAL) 1
0,2 CQE1A220Z SHEET , FRONT COVER AVR130/230BK 1
0,2 CQE1A411Z SHEET , BATTERY HARMAN 1
0,2 CQX1A1318W MANUAL , INSTRUCTION 1
0,2 CQX1A1320X MANUAL , SETUP 1
0,2 CSA1A018Z FM 1 POLE ANT 1
0,2 CSA1A020Z ANT , AM LOOP 1
1 CRE1A037 LOCKER SH08M790BO 14
Leve
l
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
0,2 CGWAVR260/240 FRONT PANEL ASS'Y 1
..3 CBT2A1064 KNOB , STANDBY 1
..3 CBT2A1065 KNOB , BACK 1
..3 CGB1A158Y BADGE , FRONT HARMAN/KARDON 1
..3 CGL1A265Y INDICATOR , POWER AVR155 1
..3 CGW2A447RHTB24 PANEL , FRONT 1
..3 CHG1A309 RUBBER 1
..3 CHR301 CLAMPER 32
..3 CHS1A032 TAPE , HEMELON 1
..3 CHS1A165 TAPE , HEMELON 1
..3 CMC2A323 PLATE , SHIELD 1
..3 CMC2A326 PLATE , EARTH AVR350 1
..3 CMC2A338 PLATE , EARTH AVR350 2
..3 CMD1A555 BRACKET , SIDE (L) 1
..3 CMD2A443 BRACKET , SIDE 1
..3 CMH2A215 HOLDER , LED AVR350 1
..3 CPE1A009 SHEET , BLIND 1
..3 CTB3+10JR SCREW 30
..3 CTWS3+10GR SCREW 1
..3 CB72 CWC4F2A17A280B CABLE , CARD(17P, 280mm) 1
Leve
l
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
0,2 CUAAVR260/240 BOTTOM CHASSIS ASS'Y 1
..3 CHD1A012ZR SCREW , SPECIAL 2
..3 CHD1A023R SCREW , SPECIAL 4
..3 CHD4A012R SCREW , SPECIAL 5
..3 CHE170 HOLDER , PCB 2
..3 CHE36-3 CLAMPER , WIRE 3
..3 CHG1A104Z CUSHUON , RUBBER 1
..3 CHG1A160Z CUSHION , RUBBER 1
..3 CHG1A373 CUSHION , FOOT AVR350 4
..3 CHS1A032 TAPE , HEMELON 4
..3 CJA2B044ZA CORD , POWER (KENIC) EUR 16A 250V 1
BOTTOM CHASSIS ASS'Y
FRONT PANEL ASSY
AVR260/230 Electrical & Mechanical Parts List
harman/kardon
AVR 260/230 Service Manual
Page 15 of 131
