Leve
l
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
....5 CLZ9Z028Z FERRITE , CORE(21.2X6.4X12.7) K5C T 1
....5 CWZAVR155BN41ZA 7P WIRE ASS'Y 1Core 3turn (2mm,500mm) 1
...4 BN81 CWB1C907200BM WIRE ASS'Y 1
...4 BN84 CWB2B905080EN WIRE ASS'Y 1
...4 BN85 CWB2B903100EN WIRE ASS'Y 1
...4 BN88 CWB2B905050EN WIRE ASS'Y 1
...4 BN92 CWB2B905100EN WIRE ASS'Y 1
...4 CN72 CJP17GA117ZY WAFER 1
...4 CN84 CJP05GB46ZY WAFER 1
...4 CN85 CJP03GA19ZY WAFER , STRAIGHT(3PIN) 1
...4 CN88 CJP05GA19ZY WAFER , STRAIGHT 1
...4 CN92 CJP05GA19ZY WAFER , STRAIGHT 1
...4 D701 CVD1L0345W31BOCT201
W
L.E.D , WHITE 1
...4 D703 CVD1L0345W31BOCT201
W
L.E.D , WHITE 1
...4 D705 CVD1L0345W31BOCT201
W
L.E.D , WHITE 1
...4 D723 CVD30ASOGCAA-S7 L.E.D , ORANGE T0L-30ASOGCAA-S7 1
...4 D727 CVD1L0345W31BOCT201
W
L.E.D , WHITE 1
...4 D778 HVD1N5819T DIODE , SCHOTTKY 1N5819 1
...4 ET03 CMD1A629 BRACKET , PCB 1
...4 FIP1 CFL17BT031GINAK FIP , AVR355(17BT31GINAK) 1
...4 IC73 HRVNJL34H380A SENSOR , REMOCON (JRC) 1
...4 IC75 HVI74ACT04MTR I.C , HEX (ST) 1
...4 IC76 HVI74HCU04AFNG I.C , INVERTER (TOSHIBA) TC74HCU04AFNG(TOSHIBA) 1
...4 IC86 HVINJM4556AL I.C , HEADPHONE (JRC) NJM4556AL 1
...4 IC87 HVINJM2068MTE1 I.C , OP AMP (JRC) NJM2068M-TE1 1
...4 JK81 CJJ4M041Y JACK , BOARD (COAX) 1
...4 JK82 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1
...4 JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE) 1
...4 JK85 CJJ9M004Y JACK , S-VHS (SILVER) 1
...4 JK86 CJJ4S028Y JACK , BOARD (3P SILVER) 1
...4 JW83 CWE8202150RV WIRE ASS'Y 1
...4 JW84 CWE8202150RV WIRE ASS'Y 1
...4 JW88 CWE8202150RV WIRE ASS'Y 1
...4 RL45 CSL4A016ZU RELAY , 12V 2C2P BC3-12H 1
...4 VR74 CSR2A037Z ENCODER 1
Leve
l
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
..3 COP12026I AVR255/230 MAIN PCB ASS'Y 1
...4 CHD3A012R SCREW , SPECIAL 5
....5 C501 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C502 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C503 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C504 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C505 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C506 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1
....5 C507 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1
....5 C508 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1
....5 C509 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1
....5 C510 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1
....5 C561 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C562 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C564 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C565 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C566 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C567 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C568 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C569 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C570 CCEA1CH101T CAP , ELECT 100UF 16V 1
....5 C571 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C572 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C573 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C574 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C575 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1
....5 C601 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C602 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C603 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C604 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C605 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1
....5 C606 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C607 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C608 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C609 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C610 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1
....5 C681 CCEA1HH100T CAP , ELECT 10UF 50V 1
....5 C682 CCEA1HH100T CAP , ELECT 10UF 50V 1
MAIN PCB ASSY
FRONT PCB ASSY
harman/kardon
AVR 260/230 Service Manual
