11
REAR - PANEL CONNECTIONS
NOTES:
• Due to copy-protection restrictions, there is no output at
the Component Video Monitor Outputs for HDCP-copy-
protected sources.
• Composite video signals are upscaled to as high as 1080i
and available at these outputs. If your video display’s best
connection is component video, it is the only video connec-
tion required from the AVR to the display.
AM and FM Antenna Terminals: Connect the included
AM and FM antennas to their respective terminals for radio reception.
Front, Center and Surround Speaker Outputs:
Use two-conductor speaker wire to connect each set of terminals
to the correct speaker. Remember to observe the correct polarity
(positive and negative connections).
Surround Back/Zone 2 Speaker Outputs: These
speaker outputs are used for the surround back channels in a 7.1-
channel home theater, or may be reassigned to a remote room for
multizone operation.
Switched AC Accessory Outlet: You may plug the
AC power cord of one source device into this outlet, and it will turn
on whenever you turn on the receiver. Do not use a source that
consumes more than 50 watts of power.
AC Power Cord: After you have made all other connections,
plug the AC power cord into an unswitched wall outlet.
AVR 2600 OM.qxd 4/29/09 12:10 PM Page 11
