11
REAR- PANEL CONNECTIONS
ENGLISH
Component Video Monitor Outputs: If you are
using one of the Component Video Inputs and your television or
video display is component-video-capable (but does not have an
HDMI input), connect these jacks to the video display.
NOTES:
• Due to copy-protection restrictions, there is no output at
the Component Video Monitor Outputs for HDCP-copy-
protected sources.
• Composite video signals are upscaled to as high as 1080i
and available at these outputs. If your video display’s best
connection is component video, it is the only video connec-
tion required from the AVR to the display.
AM and FM Antenna Terminals: Connect the included
AM and FM antennas to their respective terminals for radio reception.
Preamp Outputs: Connect these jacks to an external
amplifier if more power is desired. The Surround Back/Zone 2
Preamp Outputs may be used with an external amplifier to power
the remote zone of a multizone system.
A-BUS Port: Use a Category 5/5e cable to connect this port to
optional A-BUS equipment for multizone operation. When the A-BUS
system is used, it is possible to have a full 7.1-channel system in
the main listening room at the same time the multizone system
is in use.
Front, Center and Surround Speaker Outputs:
Use two-conductor speaker wire to connect each set of terminals
to the correct speaker. Remember to observe the correct polarity
(positive and negative connections).
Surround Back/Zone 2 Speaker Outputs: These
speaker outputs are used for the surround back channels in a 7.1-
channel home theater, or may be reassigned to a remote room for
multizone operation.
Switched AC Accessory Outlet: You may plug the
AC power cord of one source device into this outlet, and it will turn
on whenever you turn on the receiver. Do not use a source that
consumes more than 50 watts of power.
AC Power Input: After you have made all other connections,
plug the AC power cord into this receptacle and into an unswitched
wall outlet.
0139CSK - HK AVR 3600 OM Inlay ENG Marked v2.qxp:HKP1477AVR245om.v2.qxd 28/05/09 11:19 Side 11
REAR PANEL CONNECTIONS
AVR3600 harman/kardon
