T5CN5
(13) Standby mode
Standby modes :IDLE, SLOW, SLEEP, STOP
Sub clock operation(32.768kHz) :SLOW, SLEEP
(14) Clock generator
On-chip PLL (quadrupled)
Clock gear function: The high-speed clock can be divided into 1/1, 1/2, 1/4 or 1/8.
(15) Endian
Little endian
(16) Maximum operating frequency
40MHz
(17) Operating voltage range
2.7V~3.6V (with on-chip regulator)
(18) Temperature range
-20~85 degrees (except during Flash writing/ erasing)
0~70 degrees (during Flash writing/ erasing)
(19) Package
LQFP100-P-1414-0.5H (14mm
14mm, 0.5mm pitch)
