Harman Kardon AVR 2600 Service Manual

T5CN5
Table 2.1 Pin Numbers and Names (2/2)
Pin
No.
Pin name Pin
No.
Pin name
51
PK1, SCOUT,
ALARM
76 REGVCC
52
PI4, TB4OUT 77 XT1
53
PI5, TB5OUT 78 XT2
54
PB0, TDO, SWV 79 PI6, TB4IN0
55
PA0, TMS, SWDIO 80
NMI
56
PA1, TCK, SWCLK 81 MODE
57
TEST3 82
RESET
58
PJ7, INT7 83 PI7, TB4IN1
59
PB1, TDI 84 PH6, TB3IN0
60
PB2,
TRST
85 PH7, TB3IN1
61
PF3, RXIN1 86 PJ2, INT2
62
DVCC 87 PJ3, INT3
63
DVSS 88 PJ4, TB6OUT
64
PA2, TRACECLK 89 PE3, RXIN0
65
PA3, TRACEDATA0 90 TEST4
66
PA4, TRACEDATA1 91 PC0, AN0
67
PA5, TRACEDATA2 92 PC1, AN1
68
PA6, TRACEDATA3 93 PC2, AN2
69
PA7 94 PC3, AN3
70
PJ0, INT0 95 PD0, AN4, TB5IN0
71
CVCC 96 PD1, AN5, TB5IN1
72
X2 97 PD2, AN6, TB6IN0
73
CVSS 98 PD3, AN7, TB6IN1
74
X1 99 PD4, AN8
75
REGVSS 100 PD5, AN9
AVR3600 harman/kardon
143
