Harman Kardon AVR 2600 Service Manual

Ref. Designator Part Number Qty
Description
HDMI PCB ASS'Y COP12179C
R757 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
R758 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R759 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R760 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
R761 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R762 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R764 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
R765 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R766 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R767 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R768 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R770 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R771 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R772 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R776 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R777 CRJ10DF2800T RES , CHIP(1/10W, 280ohm, 1608, 1%) 1/10W, 280OHM, 1608, 1% 1 EA
R778 CRJ10DF1002T RES , CHIP 1% 10K /1/10W/F 1 EA
R779 CRJ10DJ301T RES , CHIP 300 OHMS 1608 SIZE 1 EA
R780 CRJ10DJ301T RES , CHIP 300 OHMS 1608 SIZE 1 EA
R781 CRJ10DF3901T RES, CHIP 3.9KOHM/1608/1% 3.9KOHM 1 EA
R782 CRJ10DF2200T RES , CHIP 1% (220 OHM) 1608 SIZE 1 EA
R783 CRJ10DF2800T RES , CHIP(1/10W, 280ohm, 1608, 1%) 1/10W, 280OHM, 1608, 1% 1 EA
R784 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R785 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R786 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R787 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R788 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R789 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R791 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
R792 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R794 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
R795 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
R796 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R800 CRJ10DJ623T RES , CHIP 1608 SIZE (62K OHM) 62K OHM 1 EA
R801 CRJ10DJ623T RES , CHIP 1608 SIZE (62K OHM) 62K OHM 1 EA
R802 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R803 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R804 CRJ10DJ623T RES , CHIP 1608 SIZE (62K OHM) 62K OHM 1 EA
R805 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R806 CRJ10DJ563T RES , CHIP 56K OHMS 1 EA
R807 CRJ10DJ203T RES , CHIP 1608 SIZE 1 EA
R808 CRJ10DJ512T RES , CHIP (5.1K OHM) 1608 SIZE 1 EA
R809 CRJ10DJ820T RES , CHIP (82 OHM) 1608 SIZE 1 EA
R810 CRJ10DJ683T RES , CHIP (68K OHM) 1608 SIZE 1 EA
R811 CRJ10DJ683T RES , CHIP (68K OHM) 1608 SIZE 1 EA
R812 CRJ10DJ683T RES , CHIP (68K OHM) 1608 SIZE 1 EA
R813 CRJ10DJ223T RES , CHIP (22K OHM) 1608 SIZE 1 EA
R814 CRJ10DJ223T RES , CHIP (22K OHM) 1608 SIZE 1 EA
R815 CRJ10DJ223T RES , CHIP (22K OHM) 1608 SIZE 1 EA
R818 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
Miscellaneous
BN15 CJP17GA193ZY WAFER, CARD CABLE (SMD) 1 EA
CN55 CJP26GA226ZB DIP , SOCKET (26PIN, 2.54mm, SMD) 1 EA
JK901 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
JK902 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
JK903 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
JK904 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
JK905 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
L801 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) CMM21T-900M-3H 1 EA
L802 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) CMM21T-900M-3H 1 EA
L803 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) CMM21T-900M-3H 1 EA
L804 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) CMM21T-900M-3H 1 EA
