Harman Kardon AVR 2600 Service Manual

Ref. Designator Part Number Qty
Description
USB IPOD PCB ASS'Y COP12169D
C189 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C190 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C196 CCEA1EH221T CAP , ELECT 220UF 25V 1 EA
C198 CCEA1EH221T CAP , ELECT 220UF 25V 1 EA
C215 CCEA1CH471T CAP , ELECT 470UF 16V 1 EA
C225 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1 EA
C226 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1 EA
Semiconductors
D101 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
D103 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
D921 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
IC204 CVITMP92FD28FG I.C , USB DECODER FLASH(100PIN, QFP) TOSH TMP92FD28DFG, FLASH 1 EA
IC206 HVI74HCU04AFNG I.C , INVERTER (TOSHIBA) TC74HCU04AFNG(TOSHIBA) 1 EA
IC207 CVIKIA1117S33 I.C , REGULATOR(SOT-223) KIA1117S/F33, SOT-223 1 EA
IC208 HVIRH5VT28C I.C , RESET (RICOH) RH5VT28CA-T1 1 EA
IC209 CVIKIA1117S33 I.C , REGULATOR(SOT-223) KIA1117S/F33, SOT-223 1 EA
IC211 CVINJM2505AFTE1 I.C , VIDEO AMP(4.5~9.0V , 200MW , MTP5) JRC NJM2505AF-TE1 , JRC 1 EA
IC212 CVINJM2505AFTE1 I.C , VIDEO AMP(4.5~9.0V , 200MW , MTP5) JRC NJM2505AF-TE1 , JRC 1 EA
IC213 CVINJM2505AFTE1 I.C , VIDEO AMP(4.5~9.0V , 200MW , MTP5) JRC NJM2505AF-TE1 , JRC 1 EA
IC214 HVINJM2581MTE1 I.C Dual Supply Wide Band 3ch Video Amplifier NJM2581M 1 EA
IC216 CVITL072CDR I.C , DUAL OP AMP/SOP/8P (TI) TL072CDR 1 EA
IC217 HVINJM2068MDTE1 I.C , DUAL OP AMP (JRC) NJM2068MD-TE1 1 EA
IC220 HVI74LCX32TTR I.C , OR-GATE (ST) 74LCX32TTR 1 EA
Q101 HVTKRC102S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC102S 1 EA
Q102 HVTKRC102S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC102S 1 EA
Q103 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q104 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q105 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q106 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q107 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q108 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
IC201 BVIKP1010B IC, PHOTO COUPLER (COSMO) KP1010B 1 EA
IC202 BVIKP1010B IC, PHOTO COUPLER (COSMO) KP1010B 1 EA
IC203 HVIKIA78R05PI REGULATOR (5V OUTPUT LOW DROP) KIA78R05PI 1 EA
IC215 CVITMP86F409NG I.C , IPOD UART BUFFER (TOSHIBA) TMP86F409NG(ZM) 1 EA
IC223 CVIKIA7805APIJA I.C HEAT SINK ASS'Y (CMY2A223) CVIKIA7805API/CMY2A223 1 EA
HVIKIA7805API REGULATOR, +5V 7805API (KEC) 1 EA
Resistors
R107 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R108 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R109 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R110 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R111 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R117 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R118 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R119 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R120 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R121 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R122 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R123 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R170 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R171 CRJ10DJ222T RES , CHIP (2.2K OHM) 1608 SIZE 1 EA
R172 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R173 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R174 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R177 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R178 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R179 CRJ10DJ4R7T RES , CHIP (4.7 OHM) 1608 SIZE 1 EA
R182 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R183 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
AVR3600 harman/kardon
82
