Harman Kardon AVR 2600 Service Manual

Ref. Designator Part Number Qty
Description
USB IPOD PCB ASS'Y COP12169D
R355 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
R500 CRJ10DJ4R7T RES , CHIP (4.7 OHM) 1608 SIZE 1 EA
Miscellaneous
L101 CLZ9R001Z FERRITE , CHIP BEAD(60ohm, 2012) HCB2012KF-600T40 1 EA
L102 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L105 CLZ9R001Z FERRITE , CHIP BEAD(60ohm, 2012) HCB2012KF-600T40 1 EA
L106 CLZ9R001Z FERRITE , CHIP BEAD(60ohm, 2012) HCB2012KF-600T40 1 EA
BK11 CMD1A569 BRACKET , PCB 1EA
BK12 CMD1A569 BRACKET , PCB 1EA
BN50 CJP05GA19ZY WAFER , STRAIGHT 20017WS-05 1 EA
BN55 CJP26GA240ZB PIN HEADER (26P, 2.54mm), STRAIGHT TYPE 1 EA
CN51 CJP07GA01ZY WAFER , STRAIGHT(7PIN) 00906-0017 1 EA
CN58 CJP07GA01ZY WAFER , STRAIGHT(7PIN) 00906-0017 1 EA
CN81 CJP44GA241ZB FEMALE HEADER (44P,2.54mm) , DIP/STRAIGHT 1 EA
CMY2A223 HEAT SINK ADV-500 1 EA
CTB3+8JR SCREW 00M51260308M0 1 EA
JK11 CJJ2D008Z JACK , STEREO PJ-308-02 1 EA
JK12 CJJ2D008Z JACK , STEREO PJ-308-02 1 EA
JK13 CJJ2D008Z JACK , STEREO PJ-308-02 1 EA
JK14 CJJ2D008Z JACK , STEREO PJ-308-02 1 EA
JK15 CJJ2D008Z JACK , STEREO PJ-308-02 1 EA
JK16 CJJ9N007Z JACK , DIN SOCKET(8P) DIN-801 1 EA
JK17 CJJ9L016Z JACK , IPOD CONNECTOR (36PIN) SCSI36P 1 EA
X101 COX09000E150C CRYSTAL(9MHZ) 1EA
X103 HOX12000E200C 12MHz CRYSTAL 1EA
X104 HOX00032K120I CRYSTAL , 32.768KHZ TUNING FORK 1 EA
BOTTOM CHASSIS ASS'Y
CFNCF12625SA MOTOR , FAN(60X60X25MM) 1 EA
CHD1A012ZR SCREW , SPECIAL 2EA
CHD1A023R SCREW , SPECIAL 4EA
CHD1A036FZR SCREW , SPECIAL 2EA
CHD1A065R SCREW , FLAT(2.6X4) 2 EA
CHD4A012R SCREW , SPECIAL 5EA
CHE170 HOLDER , PCB 2EA
CHE36-3 CLAMPER , WIRE 1EA
CHG1A104Z CUSHION , RUBBER 2EA
CHG1A113 RUBBER 3EA
CHG1A160Z CUSHION , RUBBER 1EA
CHG1A373 CUSHION , FOOT AVR350 4 EA
CHG1A462 CUSHION , RUBBER 1EA
CKF3A398Y PANEL , REAR 1EA
CKF3A398Z PANEL , REAR 1EA
CKL1A094 FOOT , A AVR350 2EA
CKL1A095 FOOT , B AVR350 2EA
CMD1A506 BRACKET , FAN 1EA
CMD1A702 FRAME , BOTTOM 1EA
CMD2A636 BRACKET , PCB 1EA
CTB3+10JFZR SCREW 24 EA
CTB3+6FFZR SCREW 10 EA
CTB3+8JFZR SCREW 12 EA
CTB3+8JR SCREW 7EA
CTS3+8JFZR SCREW 4EA
CTW3+12JR SCREW 2EA
CUA1A294 CHASSIS , BOTTOM 1EA
BN90 CSH1A009ZVB SWITCH , MOMS WIRE ASS'Y (2P, 80MM, RED) 1 EA
CSH1A009ZV SWITCH , MOMS 1EA
CWB4F202080UK WIRE ASS'Y (3.96MM, 80MM, 2P, RED) 1 EA
BN92 CJJ8A006ZWA RECEPTACLE(AC) WIRE ASS'Y (2P, 120MM, RD/BK) 1 EA
CJJ8A006ZW RECEPTACLE , AC(15A/250V,R-301,B21) R-301(B21) 1 EA
CWB4F002120UK WIRE ASS'Y (3.96MM, 120MM, 2P, RD/BK) 1 EA
