Harman Kardon AVR 347/230

VIDEO PCB ASSY
Ref. # Part Number
Description
Value
C422 CCEA1HH100T CAP , ELECT 10UF 50V
C423 CCEA1HH100T CAP , ELECT 10UF 50V
C431 CCEA1HH100T CAP , ELECT 10UF 50V
C432 CCEA1HH100T CAP , ELECT 10UF 50V
C433 CCEA1HH100T CAP , ELECT 10UF 50V
C451 CCEA1HH100T CAP , ELECT 10UF 50V
C452 CCEA1HH100T CAP , ELECT 10UF 50V
C453 CCEA1HH100T CAP , ELECT 10UF 50V
C462 CCEA1CH101T CAP , ELECT 100UF 16V
C464 CCEA1CH101T CAP , ELECT 100UF 16V
C467 CCEA1CH101T CAP , ELECT 100UF 16V
C469 CCEA1CH101T CAP , ELECT 100UF 16V
C472 CCEA1CH101T CAP , ELECT 100UF 16V
C474 CCEA1CH101T CAP , ELECT 100UF 16V
C486 CCEA1CH101T CAP , ELECT 100UF 16V
C488 CCEA1CH101T CAP , ELECT 100UF 16V
C602 CCEA0JH102T CAP , ELECT 1000UF 6.3V
C604 CCEA0JH102T CAP , ELECT 1000UF 6.3V
C606 CCEA0JH102T CAP , ELECT 1000UF 6.3V
C612 CCEA1HH100T CAP , ELECT 10UF 50V
C614 CCEA1HH100T CAP , ELECT 10UF 50V
C616 CCEA1HH100T CAP , ELECT 10UF 50V
C622 CCEA1HH100T CAP , ELECT 10UF 50V
C624 CCEA1HH100T CAP , ELECT 10UF 50V
C626 CCEA1HH100T CAP , ELECT 10UF 50V
C632 CCEA1HH100T CAP , ELECT 10UF 50V
C634 CCEA1HH100T CAP , ELECT 10UF 50V
C636 CCEA1HH100T CAP , ELECT 10UF 50V
C641 CCEA1HH100T CAP , ELECT 10UF 50V
C643 CCEA1HH100T CAP , ELECT 10UF 50V
C645 CCEA1HH100T CAP , ELECT 10UF 50V
C671 CCEA1CH101T CAP , ELECT 100UF 16V
C673 CCEA1HH100T CAP , ELECT 10UF 50V
C676 CCEA1CH101T CAP , ELECT 100UF 16V
C678 CCEA1CH101T CAP , ELECT 100UF 16V
BN14 CJP17GA117ZY WAFER WAFER
BN15 CJP15GB113ZY WAFER WAFER
BN81 CJP44TT212ZB PIN , HEADER (2.00MM PITCH) 44PIN, 2MM PITCH
CN41 CJP06GA19ZY WAFER , STRAIGHT DVD LOADE WAFER
CN42 CJP07GB113ZY WAFER , CARD CABLE WAFER
CN43 CJP03GB03ZY WAFER WAFER
IC62 HVIMC7809C I.C , REGULATOR FAIRCHILD
JK40 CJJ9R001Z JACK , (S-VIDEO + CVBS) JACK
JK41 CJJ9R001Z JACK , (S-VIDEO + CVBS) JACK
harman/kardon
AVR 347/230 - AVR 350/230 Service Manual
Page 72 of 95
