Harman Kardon AVR 355 Service Manual

FRONT PCB ASSY
Ref. # Part Number Description Value
BN41 CWZAVR155BN41 SHIELD WIRE ASS'Y(7P, 2MM, 500MM) WIRE
BN81 CWB1C907200BM WIRE ASS'Y WIRE
BN84 CWB2B905080EN WIRE ASS'Y WIRE
BN85 CWB2B903100EN WIRE ASS'Y WIRE
BN88 CWB2B905050EN WIRE ASS'Y WIRE
BN92 CWB2B905100EN WIRE ASS'Y WIRE
CN72 CJP17GA117ZY WAFER WAFER
CN84 CJP05GB46ZY WAFER WAFER
CN85 CJP03GA19ZY WAFER , STRAIGHT(3PIN) WAFER
CN88 CJP05GA19ZY WAFER , STRAIGHT WAFER
CN92 CJP05GA19ZY WAFER , STRAIGHT WAFER
D701 CVD1L0345W31BOCT201V L.E.D , WHITE LED
D703 CVD1L0345W31BOCT201V L.E.D , WHITE LED
D705 CVD1L0345W31BOCT201V L.E.D , WHITE LED
D723 CVD30ASOGCAA-S7 L.E.D , ORANGE LED
D727 CVD1L0345W31BOCT201V L.E.D , WHITE LED
D778 HVD1N5819T DIODE , SCHOTTKY 1N5819
ET03 CMD1A629 BRACKET , PCB BRACKET
FIP1 CFL17BT031GINK F.I.P , AVR355 FIP(FUTABA)
IC73 HRVNJL34H380A SENSOR , REMOCON SENSOR
IC75 HVI74ACT04MTR I.C , HEX JRC(74ACT04MTR)
IC76 HVI74HCU04AFNG I.C , INVERTER FAIRCHILD(74HCU04AF
N
IC86 HVINJM4556AL I.C , HEADPHONE JRC(NJM4556AL)
IC87 HVINJM2068MTE1 I.C , OP AMP JRC(NJM2068MTE1)
JK81 CJJ4M041Y JACK , BOARD (COAX) JACK
JK82 HJSTORX177L MODULE , OPTICAL(RX) OPT JACK
JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE) HEADPHONE JACK
JK85 CJJ9M004Y JACK , S-VHS (SILVER) S-VHS JACK
JK86 CJJ4S028Y JACK , BOARD (3P SILVER) JACK
JW83 CWE8202150RV WIRE ASS'Y WIRE
JW84 CWE8202150RV WIRE ASS'Y WIRE
JW88 CWE8202150RV WIRE ASS'Y WIRE
RL45 CSL4A016ZU RELAY , 12V 2C2P RELAY
VR74 CSR2A037Z ENCODER ENCODER
MAIN PCB ASSY
Ref. # Part Number Description Value
COP12026J AVR355/230 MAIN PCB ASS'YY ASS'Y
CHD3A012R SCREW , SPECIAL SCREW
C501 CCEA1HH100T CAP , ELECT 10UF 50V
C502 CCEA1HH100T CAP , ELECT 10UF 50V
C503 CCEA1HH100T CAP , ELECT 10UF 50V
C504 CCEA1HH100T CAP , ELECT 10UF 50V
C505 CCEA1HH100T CAP , ELECT 10UF 50V
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V
C507 CCBS1H331KBT CAP , CERAMIC(330PF/50V) 330PF 50V
C508 CCBS1H331KBT CAP , CERAMIC(330PF/50V) 330PF 50V
C509 CCKT1H331KB CAP , CERAMIC 330PF 50V
C510 CCBS1H331KBT CAP , CERAMIC(330PF/50V) 330PF 50V
C561 CCEA1CH101T CAP , ELECT 100UF 16V
C562 CCEA1CH101T CAP , ELECT 100UF 16V
C564 CCEA1CH101T CAP , ELECT 100UF 16V
C565 CCEA1CH101T CAP , ELECT 100UF 16V
C566 CCEA1CH101T CAP , ELECT 100UF 16V
C567 CCEA1CH101T CAP , ELECT 100UF 16V
C568 CCEA1CH101T CAP , ELECT 100UF 16V
C569 CCEA1CH101T CAP , ELECT 100UF 16V
C570 CCEA1CH101T CAP , ELECT 100UF 16V
C571 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V
C572 CCBS1H681KBT CAP , CERAMIC(680PF/50V) 680PF 50V
harman/kardon
AVR 355/230 Service Manual
Page 14 of 125
