Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
INPUT PCB ASS'Y COP12177D
D214 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
D215 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
D216 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
D442 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
D476 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
D701 HVDRLS4148SR DIODE, SWITCHING, SMD TYPE RLS4148 TE-11 1 EA
D704 CVDSS34SR DIODE , SCHOTTKY (40V,3A, DO-214AC) DELT
A
SS34 1 EA
D725 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
D727 CVD1SS355T DIODE , CHIP 1SS355(T/B) 1 EA
IC20 CVINJW1298FU1 I.C , VOL WITH INPUT SELECTOR (JRC) NJW1298FU1(PB-F 1 EA
IC21 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC22 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC23 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC24 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC25 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC26 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC28 HVINJW1159M I.C , ELECTRONIC VOLUME (2-CH) NJW1159V-TE1(PB 1 EA
IC29 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC31 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC32 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC33 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC34 HVINJM2068MTE1 I.C , DUAL OP AMP (JRC) NJM2068M-TE1 1 EA
IC40 HVITC74HCU04AFN IC , HEX INVERTER TC74HCU04AFN 1 EA
IC41 HVICS42528-CQ I.C , CODEC + DIR (CIRRUS LOGIC) CS42528-CQ 1 EA
IC42 CVIF25L008A50PAG I.C , 8Mbit SPI Serial FLASH (50MHz/8lead SOIC) F25L008A-50PAG 1 EA
IC43 CVICS497024CVZ I.C , DSP (CIRRUS LOGIC) CS497024-CVZ 1 EA
IC44 CVIM12L16161A5TG I.C, 16MB SDRAM (ESMT) M12L16161A-5TG 1 EA
IC45 CVIF25L004A100PAG I.C , 4M FLASH(8PIN SOIC) F25L004A100PAG 1 EA
IC46 CVICS49DV8CCVZ I.C , DSP (DOLBY VOLUME) CIRRUS LOGIC CS49DV8CCVZ 1 EA
IC47 CVITC74VCX541FT I,C , OCTAL BUS BUFFER (TOSHIBA) TC74VCX541FT(EL 1 EA
IC48 HVITC74VHC157FT I.C , 2-CHANNEL MUX (TOSHIBA) TC74VHC157FT(EL 1 EA
IC49 HVINJM2391DL133 I.C , CHIP REGULATOR (+3.3V) JRC NJM2391DL1-33 1 EA
IC50 CVIKIA1117S18 I.C , REGULATOR(SOT-223) KIA1117S/F18, SOT-223 1 EA
IC51 CVIKIA1117S33 I.C , REGULATOR(SOT-223) KIA1117S/F33, SOT-223 1 EA
IC52 CVIANAM1459AT I.C , U-COM (AVR2600/AVR3600) ANAM1459AT 1 EA
CVIT5CN5 I.C , U-COM (512KB/32KB, LQFP100P) TOSHIBA T5CN5(F,AAD) 1 EA
IC53 CVIM24C32WMN6TP I.C , EEPROM (32 Kbit) ST M24C32WMN6TP 1 EA
Q301 HVTKTC812TB TRANSISTOR , CHIP(TS6) AUDIO MUTING NPN KTC812T-B-RTK 1 EA
Q302 HVTKTC812TB TRANSISTOR , CHIP(TS6) AUDIO MUTING NPN KTC812T-B-RTK 1 EA
Q303 HVTKTC812TB TRANSISTOR , CHIP(TS6) AUDIO MUTING NPN KTC812T-B-RTK 1 EA
Q304 HVTKTC812TB TRANSISTOR , CHIP(TS6) AUDIO MUTING NPN KTC812T-B-RTK 1 EA
Q305 HVTKTC812TB TRANSISTOR , CHIP(TS6) AUDIO MUTING NPN KTC812T-B-RTK 1 EA
Q306 HVTKTC812TB TRANSISTOR , CHIP(TS6) AUDIO MUTING NPN KTC812T-B-RTK 1 EA
Q307 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q401 HVTKTC812TB TRANSISTOR , CHIP(TS6) AUDIO MUTING NPN KTC812T-B-RTK 1 EA
Q402 HVTKTC812TB TRANSISTOR , CHIP(TS6) AUDIO MUTING NPN KTC812T-B-RTK 1 EA
Q456 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q729 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q730 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q732 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q734 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q735 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q736 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q738 CVTKRC103S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC103S-RTK/P 1 EA
Q739 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q741 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q742 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q951 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q952 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q991 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q992 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q993 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
Q994 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
Q997 HVTKRA107S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA107S-RTK/P 1 EA
AVR3600 harman/kardon
62
