Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
INPUT PCB ASS'Y COP12177D
Q998 HVTKRC107S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC107S-RTK/P 1 EA
D221 CVD1N4003ST DIODE , RECT 1N4003 1 EA
D222 CVD1N4003ST DIODE , RECT 1N4003 1 EA
D447 HVDMTZJ12BT DIODE , ZENER MTZJ12B 1/2W 1 EA
Q311 HVTKTC2874BT
TRANSISTOR , MUTE NPN
KTC2874B 1 EA
Q457 HVTKTA1267YT
TRANSISTOR PNP
KTA1267Y 1 EA
Q458 HVTKTA1271YT
TRANSISTOR PNP
KTA1271Y 1 EA
Q731 HVTKTA1267YT
TRANSISTOR PNP
KTA1267Y 1 EA
Q733 HVTKTC3199YT
TRANSISTOR NPN
KTC3199Y 1 EA
IC27 BVIKP1010B IC, PHOTO COUPLER (COSMO) KP1010B 1 EA
IC36 HVIKIA7808API I.C , REGULATOR +8V KIA7808 (KEC) 1 EA
IC37 CVIKIA7908PI I.C , REGULATOR(TO-220IS) KIA7908PI TO-220IS 1 EA
Resistors
RN53 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN54 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN61 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
RN62 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
RN63 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
RN64 CRJ104DJ101T RES , CHIP NETWORK(1/16W, 100ohm, 1608X4) 100R (1608) 1 EA
RN65 CRJ104DJ101T RES , CHIP NETWORK(1/16W, 100ohm, 1608X4) 100R (1608) 1 EA
RN66 CRJ104DJ101T RES , CHIP NETWORK(1/16W, 100ohm, 1608X4) 100R (1608) 1 EA
RN67 CRJ104DJ101T RES , CHIP NETWORK(1/16W, 100ohm, 1608X4) 100R (1608) 1 EA
RN68 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
RN76 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN77 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN78 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN79 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN81 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN82 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN83 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN84 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN85 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN87 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN89 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
RN90 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN91 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
RN92 CRJ104DJ101T RES , CHIP NETWORK(1/16W, 100ohm, 1608X4) 100R (1608) 1 EA
RN93 CRJ104DJ330T RES , 4ARRAY (1608*4) 33 OHM/1608*4 1 EA
R203 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R204 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R205 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R206 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R207 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R208 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R209 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R210 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R211 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R212 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R213 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R214 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R215 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R216 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R219 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R220 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R221 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R222 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R223 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R224 CRJ10DJ272T RES , CHIP (2.7K OHM) 1608 SIZE 1 EA
R225 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R226 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R229 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R230 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
AVR3600 harman/kardon
63
