Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
INPUT PCB ASS'Y COP12177D
R760 CRJ10DJ105T RES , CHIP (1M OHM) 1608 SIZE 1 EA
R761 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R762 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
R763 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
R764 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R765 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R767 CRJ10DF5101T RES. CHIP (5.1K 1%) 1608 SIZE 1 EA
R770 CRJ10DJ100T RES , CHIP (10 OHM) 1608 SIZE 1 EA
R771 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R772 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R773 CRJ10DJ332T RES , CHIP (3.3K OHM) 1608 SIZE 1 EA
R774 CRJ10DJ332T RES , CHIP (3.3K OHM) 1608 SIZE 1 EA
R775 CRJ10DJ332T RES , CHIP (3.3K OHM) 1608 SIZE 1 EA
R776 CRJ10DJ332T RES , CHIP (3.3K OHM) 1608 SIZE 1 EA
R777 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
R779 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R780 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R781 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R782 CRJ10DJ272T RES , CHIP (2.7K OHM) 1608 SIZE 1 EA
R783 CRJ10DJ272T RES , CHIP (2.7K OHM) 1608 SIZE 1 EA
R784 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R785 CRJ10DJ104T RES , CHIP (100K OHM) 1608 SIZE 1 EA
R786 CRJ10DJ471T RES , CHIP (470 OHM) 1608 SIZE 1 EA
R787 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
R788 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R789 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R791 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R792 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R795 CRJ10DJ272T RES , CHIP (2.7K OHM) 1608 SIZE 1 EA
R798 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
R799 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
R800 CRJ10DJ332T RES , CHIP (3.3K OHM) 1608 SIZE 1 EA
R801 CRJ10DJ332T RES , CHIP (3.3K OHM) 1608 SIZE 1 EA
R810 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R811 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R812 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R813 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R814 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R815 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R816 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
R907 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R908 CRJ10DJ105T RES , CHIP (1M OHM) 1608 SIZE 1 EA
R909 CRJ10DJ682T RES , CHIP (6.8K OHM) 1608 SIZE 1 EA
R910 CRJ10DJ105T RES , CHIP (1M OHM) 1608 SIZE 1 EA
R932 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R960 CRJ10DJ332T RES , CHIP (3.3K OHM) 1608 SIZE 1 EA
R963 CRJ10DJ105T RES , CHIP (1M OHM) 1608 SIZE 1 EA
R966 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
R967 CRJ10DJ562T RES , CHIP (5.6K OHM) 1608 SIZE 1 EA
R968 CRJ10DJ105T RES , CHIP (1M OHM) 1608 SIZE 1 EA
R969 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R992 CRJ10DJ562T RES , CHIP (5.6K OHM) 1608 SIZE 1 EA
Miscellaneous
L604 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
L701 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L702 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L703 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
L704 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
L705 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
CN15 CJP17GA193ZY WAFER, CARD CABLE (SMD) 1 EA
BN12 CJP27GA41ZM WAFER (1.25MM, CARD CABLE, STRAIGHT 27P
)
MOLEX 52045-**45 1 EA
BN72 CJP31GA41ZM WAFER (1.25MM, CARD CABLE, STRAIGHT 31P
)
MOLEX 52045-**45 1 EA
AVR3600 harman/kardon
68
