Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
INPUT PCB ASS'Y COP12177D
BN81 CJP44GA240ZB PIN HEADER (44P,2.54mm), STRAIGHT TYPE 1 EA
CN17 CJP06GB142ZB PIN HEADER(6P, 2.54mm) 1 EA
CN20 CJP07GI237ZW LOCKING TYPE , STRAIGHT WAFER, 2.5MM A2512WV0-7P 1 EA
CN40 CJP03GA01ZY WAFER YMW025-03R 1 EA
CN52 CJP03GA01ZY WAFER YMW025-03R 1 EA
JK11 CJJ4R019W TERMINAL , IN/OUT RCA-601DA(II)-0 1 EA
JK12 CJJ4R019W TERMINAL , IN/OUT RCA-601DA(II)-0 1 EA
JK13 CJJ4R019W TERMINAL , IN/OUT RCA-601DA(II)-0 1 EA
JK14 CJJ4R037W JACK , BOARD RCA-601DA(II)-2 1 EA
JK17 CJJ9L004Z JACK , RJ-45 1EA
JK78 CJJ4S022Z JACK , BOARD RCA-325A-01 1 EA
JW70 CWE8202150AA WIRE ASS'Y 1EA
L301 CLM4B001Z COIL , MPX (FM 19KHz FILTER) 1 EA
L302 CLM4B001Z COIL , MPX (FM 19KHz FILTER) 1 EA
TUN1 CNVMW004MV1S63SA TUNER(USA) FM(SCREW : F TYPE), AM(S/LAB) KST-MW004MV1-S63SA 1 EA
X701 HOX24576E150TF CRYSTAL 24.576MHZ 1 EA
X702 HOX10000E220TF CRYSTAL(HC-49/S,ATS) 10MHz CL-22P 1 EA
HDMI PCB ASS'Y COP12179C
Capacitors
C601 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C602 CCUS1H223KC CAP , CHIP 0.022UF 50V K 1 EA
C603 HCEC1CRV2101T CAP , CHIP ELECT (100UF/16V) 100UF/16V 1 EA
C604 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C605 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C606 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C607 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C608 CCUS1H223KC CAP , CHIP 0.022UF 50V K 1 EA
C609 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C610 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C611 HCEC1CRV2101T CAP , CHIP ELECT (100UF/16V) 100UF/16V 1 EA
C612 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C613 CCUS1H102KC CAP , CHIP 1000PF 50V K 1 EA
C614 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C615 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C616 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C617 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C618 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C619 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C620 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C621 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C622 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C623 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C624 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C625 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C626 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C627 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C628 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C629 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C630 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C631 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C632 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C633 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C634 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C635 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C636 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C637 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C638 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C639 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C640 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C641 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C642 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
AVR3600 harman/kardon
69
