Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
HDMI PCB ASS'Y COP12179C
C643 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C644 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C645 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C646 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C647 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C648 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C649 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C650 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C651 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C652 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C653 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C654 CCUS1A105KC CAP , CHIP 1UF 10V K 1 EA
C655 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C656 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C657 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C658 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C659 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C660 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C661 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C662 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C663 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C664 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C665 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C666 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C667 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C668 CCUS1H123KC CAP , CHIP(1608, 50V/12NF) 1608, 50V/12NF 1 EA
C669 CCUS1C154KC CAP , CHIP 0.15UF 16V K 1 EA
C670 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C671 CCUS1H222KC CAP , CHIP 2200PF 50V K 1 EA
C672 CCUS1H123KC CAP , CHIP(1608, 50V/12NF) 1608, 50V/12NF 1 EA
C673 CCUS1C154KC CAP , CHIP 0.15UF 16V K 1 EA
C674 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C675 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C676 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C677 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C678 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C679 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C680 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C681 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C682 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C683 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C684 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C685 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C687 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C688 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C689 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C690 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C691 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C692 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C693 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C694 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C695 CCSNA1C100B CAP , CHIP TANTAL(10uF/16V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C696 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C697 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C698 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C699 CCEC1CRV471T
CAP , SMD ELECT(MANLEX RV, 16V/470, 10X10) 1EA
C700 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C701 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C702 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C703 HCEC1CRV2101T CAP , CHIP ELECT (100UF/16V) 100UF/16V 1 EA
C704 CCEC1ERV221T
CAP , SMD ELECT(MANLEX, RV, 25V/220, 8X10) 25V/220 1 EA
C705 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C707 CCEC1ERV221T
CAP , SMD ELECT(MANLEX, RV, 25V/220, 8X10) 25V/220 1 EA
C708 CCEC1CRV471T
CAP , SMD ELECT(MANLEX RV, 16V/470, 10X10) 16V/470 1 EA
AVR3600 harman/kardon
70
