Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
HDMI PCB ASS'Y COP12179C
C905 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C906 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C907 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C908 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C909 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C910 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C911 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C912 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C913 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C914 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C915 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C916 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C917 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C918 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C919 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C920 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C921 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C922 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C923 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C924 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C925 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C926 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C927 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C928 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C929 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C930 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C931 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C932 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C933 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C934 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C935 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C936 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C937 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C938 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C939 CCUS1H470JA CAP , CHIP 47PF 50V J 1 EA
C940 CCUS1H470JA CAP , CHIP 47PF 50V J 1 EA
C941 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C942 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 16V/0.1UF 1 EA
C943 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C944 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C945 CCSNA0J220B CAP , CHIP TANTAL(22uF/6.3V, NingXia XingRi) XRCA45 XXX M XXX AT 1 EA
C946 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C947 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C948 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C949 CCUS1H102KC CAP , CHIP 1000PF 50V K 1 EA
C950 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C951 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C954 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C956 CCUS1H102KC CAP , CHIP 1000PF 50V K 1 EA
C957 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C958 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C959 CCEC1ERV221T
CAP , SMD ELECT(MANLEX, RV, 25V/220, 8X10) 25V/220 1 EA
C960 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C961 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C962 CCEC1CRV471T
CAP , SMD ELECT(MANLEX RV, 16V/470, 10X10) 16V/470 1 EA
C963 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
C964 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C965 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C966 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
C967 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
C970 CCUS1H101JA CAP , CHIP 100PF 50V J 1 EA
C706 CCEA1EH222E CAP , ELECT 2200UF 25V 1 EA
AVR3600 harman/kardon
74
