Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
HDMI PCB ASS'Y COP12179C
Semiconductors
D902 CVDSS34SR
DIODE , SCHOTTKY (40V,3A, DO-214AC) DELTA SS34 1 EA
D903 CVDSS34SR
DIODE , SCHOTTKY (40V,3A, DO-214AC) DELTA SS34 1 EA
D904 CVD1SS378 DIODE , SCHOTTKY BARRIER (TOSHIBA) 1SS378(TE85L,F) 1 EA
D905 CVDSS34SR
DIODE , SCHOTTKY (40V,3A, DO-214AC) DELTA SS34 1 EA
IC101 CVISII9185ACTU
I.C , HDMI RX SW(80PIN TQFP) SILICON IMAGE SII9185ACTU 1 EA
IC102 CVITC74VHC08FT I.C (TOSHIBA) QUAD 2-INPUT AND GATE TC74VHC08FT 1 EA
IC103 CVISII9134CTU IC , HDMI TX(100PIN, TQFP) SII9134CTU 1 EA
IC104 HVITC74HC4094FN I.C 8-BIT SHIFT AND STORE REGISTER (3-STA
T
TC74HC4094AFN 1 EA
IC105 CVISN74ALVCH16827DGG I.C , BUFFER/DRIVER (TI) SN74ALVCH16827DGGR , TI 1 EA
IC106 CVISN74ALVCH16827DGG I.C , BUFFER/DRIVER (TI) SN74ALVCH16827DGGR , TI 1 EA
IC107 CVISN74ALVCH16827DGG I.C , BUFFER/DRIVER (TI) SN74ALVCH16827DGGR , TI 1 EA
IC108 CVITC74VCX541FT I,C , OCTAL BUS BUFFER (TOSHIBA) TC74VCX541FT(EL 1 EA
IC109 CVISII9135ACTU I.C , HDMI RX(REVISION A,TQFP-144P) SII9135ACTU 1 EA
IC110 CVISN74ALVCH16827DGG I.C , BUFFER/DRIVER (TI) SN74ALVCH16827DGGR , TI 1 EA
IC111 CVINJM2566V I.C , NJM2566AV(TE1) JRC NJM2566AV-TE1(P 1 EA
IC112 CVIFLI30336AC I.C , VIDEO PROCESSOR (GENESIS) FLI30336 1 EA
IC113 CVIA3S56D40ETPG5 I.C, 256MB DDR SDRAM A3S56D40ETP-G5 1 EA
IC114 CVIF49L320UA70TG I.C , 32M FLASH(48PIN TSOPI) F49L320UA70TG 1 EA
IC115 CVIADV7342BSTZ I.C , VIDEO ENCODER ADV7342BSTZ 1 EA
IC116 CVIMK2302S01T I.C , BUFFER (IDT) MK23020S-01T(IDT) 1 EA
IC117 CVIA3S56D40ETPG5 I.C, 256MB DDR SDRAM A3S56D40ETP-G5 1 EA
IC118 HVIKIC7SZ08FU I.C ,INPUT AND GATE (USV PACKAGE) KIC7SZ08FU-RTK 1 EA
IC120 HVINJM2391DL125 I.C , CHIP REGULATOR (+2.5V) JRC NJM2391DL1-25 1 EA
IC121 CVISI8005QTL IC , DCDC Converter (3.5A, SOP8) SANKEN SI-8005Q 1 EA
IC122 CVISI8005QTL IC , DCDC Converter (3.5A, SOP8) SANKEN SI-8005Q 1 EA
IC123 CVIAT24C02NSU18 I.C , EEPROM (2K) AT24C02BN-SH-T 1 EA
IC124 CVITC7MZ4052FK I.C , 4CH MUX (TOSHIBA) TC7MZ4052FK(EL) 1 EA
IC125 HVIKIC7SZ08FU I.C ,INPUT AND GATE (USV PACKAGE) KIC7SZ08FU-RTK 1 EA
IC126 CVINJM2595MTE1 I.C , VIDEO S/W (JRC) NJM2595M-TE1(PB 1 EA
IC127 CVIKIA1117S50 I.C , REGULATOR(SOT-223) KIA1117S50-RTK/P 1 EA
IC128 CVINJM2845DL133 I.C , REGULATOR(3.3V, TO-252-3) JRC NJM2845DL1-33-T 1 EA
IC129 CVINJM2845DL118 IC, NJM2845DL1-18(TE1) JRC NJM2845DL-18-TE 1 EA
IC130 CVISI8005QTL IC , DCDC Converter (3.5A, SOP8) SANKEN SI-8005Q 1 EA
IC131 CVI74FCT38072DCGI I.C , CLOCK DRIVER (IDT) IDT74FCT38072DCGI , IDT 1 EA
Q901 CVTKRC103S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC103S-RTK/P 1 EA
Q902 CVTKRC103S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC103S-RTK/P 1 EA
Q903 CVTKRC103S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC103S-RTK/P 1 EA
Q904 CVTKRC103S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC103S-RTK/P 1 EA
Q905 HVTKRA102S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA102S-RTK/P 1 EA
Q906 HVTKRA102S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA102S-RTK/P 1 EA
Q907 HVTKRA102S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA102S-RTK/P 1 EA
Q908 CVTUPA672T F.E.T (NEC) UPA672T-T1-A 1 EA
Q909 HVTKRA102S TRANSISTOR, CHIP BUILT-IN BIAS PNP KRA102S-RTK/P 1 EA
Q910 CVTUPA672T F.E.T (NEC) UPA672T-T1-A 1 EA
Q911 CVTUPA672T F.E.T (NEC) UPA672T-T1-A 1 EA
Q912 CVTUPA672T F.E.T (NEC) UPA672T-T1-A 1 EA
Q913 CVTUPA672T F.E.T (NEC) UPA672T-T1-A 1 EA
Q914 CVTKRC103S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC103S-RTK/P 1 EA
Q915 HVTKRC111S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC111S-RTK/P 1 EA
Q916 CVTKRC103S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC103S-RTK/P 1 EA
Q917 HVTKRC114S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC114S-RTK/P 1 EA
Q918 HVTKRC114S TRANSISTOR, CHIP BUILT-IN BIAS NPN KRC114S-RTK/P 1 EA
Resistors
RN01 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN02 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN03 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN04 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN05 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN06 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN07 CRJ104DJ220T RES,4ARRAY (22 OHM) 22X4/2012 1 EA
AVR3600 harman/kardon
75
