Harman Kardon AVR 3600 Service Manual

Ref. Designator Part Number Qty
Description
HDMI PCB ASS'Y COP12179C
RN08 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN09 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN10 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN11 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN12 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN13 CRJ104DJ220T RES,4ARRAY (22 OHM) 22X4/2012 1 EA
RN14 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN15 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN16 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN17 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN18 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN19 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN20 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN21 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN22 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN23 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN24 CRJ104DJ220T RES,4ARRAY (22 OHM) 22X4/2012 1 EA
RN25 CRJ104DJ220T RES,4ARRAY (22 OHM) 22X4/2012 1 EA
RN26 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN27 CRJ062IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X2) MNR02M0APJ330 1 EA
RN28 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN29 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN30 CRJ062IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X2) MNR02M0APJ330 1 EA
RN31 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN32 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN33 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN34 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
RN35 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
RN36 CRJ062IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X2) MNR02M0APJ330 1 EA
RN37 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN38 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
RN39 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
RN40 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN41 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
RN42 CRJ062IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X2) MNR02M0APJ330 1 EA
RN43 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN44 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
RN45 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
RN46 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
RN47 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN48 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
RN49 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN50 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
RN51 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN52 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
RN53 CRJ062IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X2) MNR02M0APJ330 1 EA
RN54 CRJ064IJ330T RES , CHIP NETWORK(1/16W, 33ohm, 1005X4) MNR04M0APJ330 1 EA
R601 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R602 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R603 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R604 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R605 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R606 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R607 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R608 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R609 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R610 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R611 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R612 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R613 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R614 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R615 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
R616 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
R617 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
